LP16 S
ERIES
ANTI-VANDAL
SWITCHES
A
PPLICATIONS
/ M
ARKETS
DETECTOR
SWITCHES
Audio / Visual
Computer Peripherals
Instrumentation
KEYLOCK
SWITCHES
DIP
SWITCHES
Networking
Telecommunication
NAVIGATION
SWITCHES
RoHS
S
PECIFICATIONS
Electrical Rating:
100mA, 20VDC
Life Expectancy:
50,000,000 Cycles
Contact Resistance:
150mΩ Max.
Insulation Resistance:
10MΩ Min. at 500VDC
Dielectric Strength:
500VAC for 1 Minute
Operating Temperature:
-5°C to 60°C
Operating Force:
250gf ± 50gf
Total Travel:
3.3mm ± 0.3mm
Functions:
SPST, Off-(On), Momentary
F
EATURES
& B
ENEFITS
• 50,000,000 cycle life expectancy
• Long 3.3mm travel
• Illumination options
• 2 cap sizes
• Price competitive
SLIDE
SWITCHES
ROTARY
SWITCHES
ROCKER
SWITCHES
PUSHBUTTON
SWITCHES
P
ART
N
UMBER
C
ONFIGURATOR
Series
Function
Stye
Circuit
Cap Size
Cap
Configuration
Cap Color
Diffuser
Color
LED Color Options
SNAP ACTION
SWITCHES
LP16
OA
1
- SPST
A
- 12.2mm Sq.
B
- 14.6mm Sq.
S
- Sculptured
T
- Transparent*
R
- Red
G
- Green
B
- Blue
Y
- Yellow
TACTILE
SWITCHES
W
- White
R
- Red
G
- Green
B
- Blue
Y
- Yellow
T
- Transparent**
N
- No LED
R
- Red
G
- Green
Y
- Yellow
B
- Blue
* Always used when a diffuser color is defined
** Always used when a cap color is defined
CAP
OPTIONS
TOGGLE
SWITCHES
Specifications subject to change without notice
www.e-switch.com
800.867.2717
1
