SERIES 800A SWITCHES
SPECIFICATIONS
Life Expectancy:
Contact Resistance:
Insulation Resistance:
Dielectric Strength:
Actuation Force:
50,000 cycles typical
10m
1
max. typical @ 2-4 VDC
100mA for both silver and gold plated contacts
1,000M
1
min.
1,000 V rms @ sea level
200 ± 50 gf
PUSHBUTTON
SWITCHES
CAP COLOR
SNAP-ACTION
SWITCHES
CAP
OPTIONS
DETECTOR
SWITCHES
ROTARY
SWITCHES
Model No.
WSP8
WSP9
ON
OFF
Type
(ON)
(ON)
SCHEMATIC
P.C. MOUNTING
( ) = Momentary
KEYLOCK
SWITCHES
DIP
SWITCHES
SLIDE
SWITCHES
SEAL
CAP
ROCKER
SWITCHES
TOGGLE
SWITCHES
NAVIGATION
SWITCHES
TACT
SWITCHES
PUSHBUTTON SWITCHES - SUB-MINIATURE
Contact Rating:
1A @ 120 VAC
Operating Temperature: -30°C to +85°C
MATERIALS
Case:
Diallyl Phthalate (DAP)
Glass filled nylon or glass filled polyester
Diallyl Phthalate (DAP)
Stainless steel
Silver or Gold plated copper alloy
FEATURES & BENEFITS
Subminiature design
Butt contact design
IP-67 sealed option
APPLICATIONS/MARKETS
Telecommunications
Networking
Computers/servers
Performance audio
Instrumentation
Low power on/off designs
External hard drives and modems
Plunger:
Bushing:
Housing:
Contacts:
SPDT
WSP8
www.e-switch.com
▲
▲
▲
▲
▲
▲
HOW TO ORDER
SERIES
MODEL NO.
TERMINATION
CONTACT
MATERIAL
800 A
WSP8
WSP9
M2
M6
M61
M7
VS2
Q = Silver
R = Gold
E
E = Epoxy
Sealed at
Base of
Terminal
See Cap Options
Example Ordering Number
800A_ WSP9_ M7_ R_ E
Specifications subject to change without notice.
info
@
e-switch.com
77
M7
SPST
SCHEMATIC
P.C. MOUNTING
SPST
SCHEMATIC
P.C. MOUNTING
SNAP-ACTION
SWITCHES
CONTACT MATERIAL OPTIONS
Q
Fixed Terminal:
Moving Contact:
Rating:
Silver plated copper alloy
Silver plated copper alloy
1 AMPS @ 120 VAC or 28 VDC
Fixed Terminal:
Moving Contact:
Rating:
Copper alloy with gold plate over nickel plate
Copper alloy with gold plate over nickel plate
0.4 VA max. @ 20 VAC or DC max.
