SPECIFICATIONS
Housing Material:
Screw:
Terminals:
Cover:
Screw Torque:
Wire Range:
Rated:
Operating Temp:
Withstanding:
Insulation Resistance:
Poles
A
2
20.4
3
29.9
4
39.4
5
48.9
6
58.4
7
67.9
8
77.4
9
86.9
10
96.4
11
105.9
12
115.4
13
124.9
14
134.4
Pitch
950
950=9.5mm
PA 66 UL94V-0 Black
M3.5 Nickel Plated Steel
Tin Plated Brass
PC Transparent
15.7 In-Lb
12~22 AWG
25 Amperes AC300V
-55C ~ +105C
AC 200V min
>1000MΩ or more @ DC500V
Dimensions
B
Poles
9.50
15
19.0
16
28.5
17
38.0
18
47.5
19
57.0
20
66.5
21
76.0
22
85.5
23
95.0
24
104.5
25
114.0
26
123.5
27
Positions
XX
02-27
A
143.9
153.4
162.9
172.4
181.9
191.4
200.9
210.4
219.9
229.4
238.9
248.4
257.9
B
133.0
142.5
152.0
161.5
171.0
180.5
190.0
199.5
209.0
218.5
228.0
237.5
247.0
Color
BK
A
B
C
C
D
D
E
E
Series
CMTB
Terminal Block
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Type
HD122X
Barrier Strip, R/A
X; C=With Cover
[blank] = No Cover
Black
F
Date
12/06/11
12/06/11
12/06/11 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
CMTB-HD122X-950-XX-BK
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: in
5
6
Description: Barrier Type Terminal Block
