PB3506 thru PB3510
www.vishay.com
Vishay General Semiconductor
Enhanced isoCink+
TM
Bridge Rectifiers
FEATURES
isoCink+™
• UL recognition file number E312394 (QQQX2)
UL 1557 (see *)
• Enhanced high-current density single in-line
package
~
+
~
-
-
~
~
+
• Superior thermal conductivity
• Solder dip 275 °C max. 10 s, per JESD 22-B106
• Compliant to RoHS Directive 2002/95/EC and in
accordance to WEEE 2002/96/EC
Case Style PB
TYPICAL APPLICATIONS
General purpose use in AC/DC bridge full wave rectification
for switching power supply, home appliances and
white-goods applications.
+
~
~
-
*Tested to UL standard for safety electrically isolated
semiconductor devices. UL 1557 4th edition.
Dielectric tested to maximum case, storage and junction
temperature to 150 °C to withstand 1500 V.
Epoxy meets UL 94 V-0 flammability rating.
MECHANICAL DATA
Case:
PB
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS compliant, commercial grade
Terminals:
Matte tin plated leads, solderable
J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test
Polarity:
As marked on body
Mounting Torque:
10 cm-kg (8.8 inches-lbs) max.
Recommended Torque:
5.7 cm-kg (5 inches-lbs)
per
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
I
R
V
F
at I
F
= 17.5 A
T
J
max.
35 A
600 V, 800 V, 1000 V
350 A
10 μA
0.90 V
150 °C
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Average rectified forward current (Fig. 1, 2)
Non-repetitive peak forward surge current
8.3 ms single sine-wave, T
J
= 25 °C
Rating for fusing (t < 8.3 ms) T
J
= 25 °C
Operating junction and storage temperature range
Notes
(1)
With heatsink
(2)
Without heatsink, free air
T
C
= 91 °C
(1)
T
A
= 25 °C
(2)
SYMBOL
V
RRM
I
O
I
FSM
I
2
t
T
J
, T
STG
PB3506
600
PB3508
800
35
4.2
350
508
- 55 to + 150
PB3510
1000
UNIT
V
A
A
A
2
s
°C
Revision: 07-Feb-12
Document Number: 84807
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PB3506 thru PB3510
www.vishay.com
Vishay General Semiconductor
TEST CONDITIONS
I
F
= 17.5 A
rated V
R
4.0 V, 1 MHz
T
A
= 25 °C
T
A
= 125 °C
T
A
= 25 °C
T
A
= 125 °C
SYMBOL
V
F
I
R
C
J
TYP.
1.00
0.90
-
115
105
MAX.
1.10
1.00
10
500
-
UNIT
V
μA
pF
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum instantaneous forward
voltage per diode
(1)
Reverse current per diode
(2)
Typical junction capacitance per diode
Notes
(1)
Pulse test: 300 μs pulse width, 1 % duty cycle
(2)
Pulse test: 10 ms pulse width
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance
Notes
(1)
With 60 W air cooled heatsink
(2)
Without heatsink, free air
SYMBOL
R
JC
(1)
R
JA
(2)
PB3506
PB3508
0.8
20
PB3510
UNIT
°C/W
ORDERING INFORMATION
(Example)
PREFERRED P/N
PB3506-E3/45
UNIT WEIGHT (G)
7.49
PREFERRED PACKAGE CODE
45
BASE QUANTITY
20
DELIVERY MODE
Tube
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
40
35
30
25
20
15
10
5
0
0
20
40
60
80
100
120
140
160
T
C
Measurement
With Heatsink
Sine-Wave, R-Load
5
Average Forward Rectified Current (A)
Average Forward Output Current (A)
4
3
2
Without Heatsink
Sine-Wave, R-Load
Free Air, T
A
1
0
0
25
50
75
100
125
150
Case Temperature (°C)
Ambient Temperature (°C)
Fig. 1 -
Derating Curve Output Rectified Current
Fig. 2 -
Forward Current Derating Curve
Revision: 07-Feb-12
Document Number: 84807
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PB3506 thru PB3510
www.vishay.com
Vishay General Semiconductor
1000
90
Forward Power Dissipation (W)
80
70
60
50
40
30
20
10
0
0
4
8
12
16
20
24
28
32
36
40
Instantaneous Reverse Current (µA)
T
A
= 150 °C
100
T
A
= 125 °C
T
A
= 100 °C
10
T
A
= 85 °C
1
T
A
= 25 °C
0.1
0.01
10
20
30
40
50
60
70
80
90
100
Average Forward Current (A)
Percent of Rated Peak Reverse Voltage (%)
Fig. 3 -
Forward Power Dissipation
Fig. 5 -
Typical Reverse Characteristics Per Diode
100
1000
T
A
= 150 °C
T
A
= 125 °C
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mV
p-p
Instantaneous Forward Current (A)
10
T
A
= 100 °C
T
A
= 25 °C
1
T
A
= 85 °C
Junction Capacitance (pF)
1.1
1.2
100
0.1
0.4
10
0.5
0.6
0.7
0.8
0.9
1.0
0.1
1
10
100
Instantaneous Forward Voltage (V)
Reverse Voltage (V)
Fig. 4 -
Typical Forward Characteristics Per Diode
Fig. 6 -
Typical Junction Capacitance Per Diode
Revision: 07-Feb-12
Document Number: 84807
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PB3506 thru PB3510
www.vishay.com
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
Case Type PB
Front
Side
View
0.118 (3.0) x 45°
CHAMFER
1.193 (30.3)
1.169 (29.7)
0.201 (5.1)
0.177 (4.5)
Vishay General Semiconductor
Side
View
0.161 (4.1)
0.138 (3.5)
0.799 (20.3)
0.776 (19.7)
0.441 (11.2)
0.425 (10.8)
0.106 (2.70)
0.091 (2.30)
0.094 (2.40)
0.079 (2.00)
0.205 (5.20)
0.189 (4.80)
0.145 (3.7)
0.130 (3.3)
120° TYP.
5° TYP.
0.134 (3.4)
0.118 (3.0)
5° TYP.
0.118 (3.0)
0.102 (2.6)
0.165 (4.20)
0.150 (3.80) 0.708 (18.0)
0.669 (17.0)
0.043 (1.10)
0.035 (0.90)
0.402 (10.2)
0.386 (9.80)
0.303 (7.70)
0.287 (7.30)
0.303 (7.70)
0.287 (7.30)
0.032 (0.80)
0.024 (0.60)
Back
Side
View
1.041 (26.44) REF.
0.088 (2.24)
REF.
0.070 (1.78) REF.
0.633 (16.07)
REF.
0.214 (5.44) REF.
0.066 (1.68)
REF.
Revision: 07-Feb-12
Document Number: 84807
4
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
