HDMKP
Vishay ESTA
Capacitors for Power Electronics
FEATURES
•
•
•
•
•
•
High RMS current rating: up to 150 A
High impulse current rating: up to 25 kA
Low self-inductance of < 70 nH
High reliability and life expectancy
Withstands heavy-duty shock and vibration
Non-polar dielectric
APPLICATIONS
•
DC-linking and DC-filtering in industry and traction
converters
•
DC-linking in low - power drives
•
DC-linking in windturbine converters
•
Impulse discharge capacitors for magnetizing and welding
•
Replacement of aluminum electrolytic capacitors (lower
capacitance, higher currents)
•
AC filter in UPS
QUICK REFERENCE DATA
DESCRIPTION
Dielectric
Dissipation factor (tan
δ
0
)
Capacitance tolerance
Operating temperature (hot spot)
Inductance
Lifetime expectancy
Reliability
Test voltage
Casing material
Filling
Standards
VALUE
Metallized polypropylene
< 2 x 10
-4
/1 kHz
±5%
θ
min.
- 40 °C
θ
max.
+ 80 °C
< 70 nH
100 000 h at U
R
and < 70 °C hotspot
100 FIT
Terminal/terminal = 1.5 x U
RDC
, 10 s terminal/case = 2 x U
RDC
+ 1000 V
AC
, 60 s
Aluminum/bergamid 3700 UF
Resin dry, UL 94 V-0
IEC 61071-1, IEC 61881 and EN61071-1
DIMENSIONS
9.2
± 0.5
8
± 0.5
± 0.5
35
± 1
35
± 1
±1
Bergamid
Aluminum
27
± 0.5
35
Bergamid
Aluminum
Rating
plated
Ø
84.4
±1
H
±1
±1
H
±1
Rating
plated
Ø
84.4
±1
Aluminum
H
Ø 116
±1
± 0.5
±1
Ø 116
± 0.5
16
± 1
16
Ø 17
Ø 15
M8
9.2
± 0.5
32
± 0.5
(4)
(19)
32
± 0.5
M8
Ø 16
M8
M12 - 10
Nm
Ø 17
Ø 15
± 0.5
± 0.5
27
(4)
Ø 17
A (2:1)
A (1.5:1)
Ø 17
A (1.5:1)
A (2:1)
Drawing 1
i.e.: HDMKP...-...I
www.vishay.com
1
Drawing 2
i.e.: HDMKP...-...B
Drawing 3
i.e.: HDMKP...-...B
Drawing 4
i.e.: HDMKP...-...I
Document Number: 13115
Revision: 17-Mar-10
For technical questions, contact:
esta@vishay.com
9.2
± 0.5
50
± 0.5
(19)
Ø 16
M8
50
± 0.5
27
16
M12 - 10
Nm
M12 - 10
Nm
16
M12 - 10
Nm
±1
H
±1
Rating
plated
Aluminum
Rating
plated
35
Bergamid
±1
27
Bergamid
± 0.5
9.2
A
A
A
8
± 0.5
E-016-651 (2 x)
brass
nickel plated
M8 x 12
Torque 6
Nm
M8
E-016-658 (2 x)
Torque 6
Nm
brass
nickel plated A
E-016-658 (2 x)
brass
nickel plated
M8 x 12
Torque 6
Nm
E-016-651 (2 x)
brass
nickel plated
M8 x 12
Torque 6
Nm
