501568-0409 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> 501568-0409

Preview

501568-0409: Description2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT; CategoryThe connector; File Size188KB，3 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet Parametric Compare View All

501568-0409 Overview

2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT

501568-0409 Parametric

Parameter Name	Attribute value
Contact materials	PHOSPHOR BRONZE
Terminal spacing	1 mm
Total number of contacts	2
Processing package description	ROHS COMPLIANT
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	501568
Contact surface matching	tin
Contact coated terminals	tin
Connection Type	Dual board connector
Connector male and female	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	right angle
Installation type	BOARD
Number of load rows	1
Terminal type	surface mount
UL flammability code	94V-2

Preview

Download Datasheet

View All

501568-0409 Related Products

	501568-0409	501568-0209	501568-0309	501568-0509	5015680509
Description	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT
Contact materials	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE
Terminal spacing	1 mm	1 mm	1 mm	1 mm	1 mm
Total number of contacts	2	2	2	2	2
Processing package description	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT
Lead-free	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes
China RoHS regulations	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer Series	501568	501568	501568	501568	501568
Contact surface matching	tin	tin	tin	tin	tin
Contact coated terminals	tin	tin	tin	tin	tin
Connection Type	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector
Connector male and female	Pin	Pin	Pin	Pin	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Installation method	right angle	right angle	right angle	right angle	right angle
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD
Number of load rows	1	1	1	1	1
Terminal type	surface mount	surface mount	surface mount	surface mount	surface mount
UL flammability code	94V-2	94V-2	94V-2	94V-2	94V-2
