SUBSTRATE AMPLIFIERS
AFSB SERIES
FEATURES
• Ideal building blocks for your own
design : low-noise, interstage and
output modules
• Available with low and medium
power levels
• 25 mil 50 ohm microstrip interface
• Ideal for gain blocks and drivers
OPTIONS
• Hermetic sealing
• Lower noise figure and customized
designs available
AFSB-00102000-45-10P TYPICAL DATA
22
GAIN (dB)
20
18
16
6
5
4
3
0.1
2
4
6
10
8
12
FREQUENCY (GHz)
GAIN
FLATNESS
(±dB, Max.)
1
1
1
1.5
1.5
1.75
2
2.5
NOISE FIGURE (dB)
14
16
18
20
MODEL
NUMBER
AFSB-00500100-09-10P
AFSB-01000200-09-10P
AFSB-02000400-15-10P
AFSB-02000800-18-10P
AFSB-12001800-20-10P
AFSB-08001800-25-10P
AFSB-06001800-28-10P
AFSB-02001800-30-10P
FREQUENCY
RANGE
(GHz)
0.5–1
1–2
2–4
2–8
12–18
8–18
6–18
2–18
GAIN
(dB, Min.)
24
28
30
20
20
20
23
20
NOISE
FIGURE
(dB, Max.)
0.9
0.9
1.5
1.8
2
2.5
2.8
3
VSWR
IN/OUT
(Max.)
2:1
2:1
2:1
2:1
2:1
2:1
2:1
2:1
OUTPUT POWER
@ 1 dB COMP.
(dBm, Min.)
10
10
10
10
10
10
10
10
NOM. DC
POWER
(+15 V, mA)
125
150
150
240
240
240
150
150
OCTAVE AND MULTIOCTAVE
ULTRA-WIDEBAND
AFSB-00100100-16-18P
AFSB-00100200-15-10P
AFSB-00100400-20-10P
AFSB-00100600-20-10P
AFSB-00100800-25-10P
AFSB-00101800-45-10P
AFSB-00102000-45-10P
0.1–1
0.1–2
0.1–4
0.1–6
0.1–8
0.1–18
0.1–20
13
36
28
20
18
18
16
1
1
1.25
1.5
2
2.5
2.75
1.6
1.5
2
2
2.5
4.5
4.5
2.5:1
2:1
2:1
2:1
2:1
2:1
2.5:1
18
10
10
10
10
10
10
150
150
240
240
240
240
240
MEDIUM POWER
AFSB-00100600-48-18P
AFSB-06001800-48-18P
AFSB-02001800-70-18P
0.1–6
6–18
2–18
18
20
20
2
2
2.75
4.8
4.8
7
2:1
2:1
2:1
18
18
18
375
150
375
NOTE: See page 66 for outline.
