BROADBAND POWER DIVIDERS
FEATURES
•
•
•
•
•
Multioctave bands
Microstrip construction
Low loss
High isolation
Small size
MITEQ offers a broad range of Wilkinson-type power dividers covering multioctave bands from 2 to 18 GHz, and
custom power dividers up to 40 GHz are also available. Power dividers up to 16-way are available as standard
products. These products feature excellent amplitude, phase balance and lowest possible loss. We can provide
these components as drop-in functions for those applications that require higher levels of integration. We offer MIL-
STD-883 screening and custom connector options.
Phase
Balance
(±Deg.,
Max.)
Divide
By
Model
Number
Frequency
Range
(GHz)
Insertion
Loss
(dB, Max.)
Isolation
(dB, Min.)
Amplitude
Balance
(±dB, Max.)
VSWR
In
(Max.)
VSWR
Out
(Max.)
Outline
STANDARD, MULTIOCTAVE BAND MODELS
D0238
D0239
D0237
D0236
D0258
D0249
D0279
D0289
D0438
D0437
D0436
D0458
D0449
D0479
D0489
D0837
D0836
D0858
D0849
D0879
D0889
D1636
D1658
2–18
2–26.5
2–12.4
2–8
5–18
4–26.5
12–26.5
18–40
2–18
2–12.4
2–8
5–18
4–26.5
12–26.5
18–40
2–12.4
2–8
5–18
4–26.5
12–26.5
18–40
2–8
5–18
1.2
2.5
0.6
0.5
0.6
1.2
1
1.5
2.5
1.7
0.9
1.5
2.5
1.8
2.5
2.8
1.5
2
3.7
2.4
3.5
2.2
3.5
20
20
20
20
20
18
18
17
20
20
20
20
16
16
17
20
20
20
16
16
17
20
20
0.25
0.5
0.3
0.2
0.2
0.4
0.2
0.5
0.4
0.35
0.35
0.35
0.5
0.5
0.5
0.4
0.4
0.5
0.6
0.5
0.5
0.5
0.5
4
5
3
2
3
4
3
5
5
4
4
5
6
6
5
5
5
7
7
7
5
5
7
1.45:1
1.6:1
1.4:1
1.4:1
1.4:1
1.6:1
1.6:1
1.8:1
1.6:1
1.5:1
1.5:1
1.6:1
1.7:1
1.75:1
1.8:1
1.6:1
1.6:1
1.7:1
1.8:1
1.8:1
1.8:1
1.7:1
1.8:1
1.35:1
1.5:1
1.35:1
1.3:1
1.4:1
1.6:1
1.6:1
1.7:1
1.4:1
1.4:1
1.25:1
1.4:1
1.6:1
1.6:1
1.7:1
1.4:1
1.25:1
1.4:1
1.6:1
1.6:1
1.7:1
1.25:1
1.5:1
2
2
3
3
3
3
3
3
4
4
4
5
5
5
5
6
6
7
7
8
8
9
10
2
4
8
16
Electrical performance of multioctave models can be optimized over narrower bandwidths for a particular parameter. Electrical options include: Lower insertion loss,
lower VSWR, higher isolation. Custom packaging also available. Examples of custom models previously shipped are shown below. Consult factory for options.
OPTIMIZED PERFORMANCE MODELS
2
4
8
119732
127071
123287
125965
126459
2.8–3.2
15.7–16.2
8–14
8–12.4
0.95–1.45
0.5
0.5
1.2
1.1
0.8
20
20
20
20
20
0.2
0.2
0.25
0.35
0.5
3
10
3
4
6
1.4:1
1.5:1
1.4:1
1.5:1
1.45:1
1.4:1
1.5:1
1.4:1
1.5:1
1.45:1
Contact factory
Contact factory
Contact factory
Contact factory
Contact factory
Power handling in a splitter application: 30 W CW @ load VSWR < 1.2:1, 10 W CW @ load VSWR < 2:1.
ENVIRONMENTAL CONDITIONS
Operating temperature . . . . . . . . . . . . . . . . 0 to 70°C
Storage temperature . . . . . . . . . . . . . . . . . . -30 to +85°C
Power handling . . . . . . . . . . . . . . . . . . . . . . P
in
maximum equals 20 W into 1.2:1 load, all ports.
13
BROADBAND POWER DIVIDER OUTLINE DRAWINGS
1, 2 and 3
0.104 [2.64] DIA. THRU
TYP. (4) HOLES
"SMA" FEMALE
CONNECTOR,
TYP. (3) PLACES
0.18 [4.57]
TYP.
4 and 5
0.50 [1.27]
TYP.
"SMA" FEMALE
CONNECTOR
TYP. (5) PLACES
0.25
[6.35]
0.25 [6.35]
TYP. (5) PLACES
0.818
[20.78]
0.50
[12.7]
J1
J0
0.25 [6.35]
0.25 [6.35]
1.00
[25.4]
J2
0.31 [7.87]
J4
J3
J2
J1
0.09
[2.29]
0.31
[7.87]
A
0.31
[7.87]
OUTLINE
1
DIM A
3.5 [88.90]
0.25
[6.35]
TYP. (3) PLACES
0.36
[9.14]
0.104 [2.64] DIA. THRU
TYP. (4) HOLES
A
0.31 [7.87]
0.104 [2.64] DIA. THRU
TYP. (2) HOLES
"SMA" FEMALE
CONNECTOR,
TYP. (3) PLACES
0.18 [4.57]
TYP.
J0
1.84
[46.74]
0.075 [1.91]
0.818
[20.78]
J1
0.25 [6.35]
0.995 [25.27]
1.00
[25.4]
0.18 [4.57] TYP.
0.36
[9.14]
J0
0.50
[12.7]
0.25 [6.35]
J2
1.99 [49.83]
0.09
[2.29]
A/2
A
0.25
[6.35]
TYP. (3) PLACES
0.36
[9.14]
OUTLINE
2
3
DIM A
1.5 [38.10]
1.02 [25.91]
OUTLINE
4
5
DIM A
2.5 [63.50]
1.4 [35.56]
6, 7 and 8
3.99 [101.35]
1.995
[50.67]
0.36 [9.14]
0.36 [9.14]
0.104 [2.64] DIA. THRU
TYP. (4) HOLES
3.84 [97.54]
0.018 [0.46] TYP.
0.075
[1.91]
0.018 [0.46]
TYP.
9 and 10
7.99 [202.95]
3.995 [101.47]
0.075 [1.91]
0.104 [2.64] DIA. THRU
TYP. (4) HOLES
7.84 [199.14]
JO
JO
0.31
[7.87]
A
0.31
[7.87]
J1
J2
J3
0.25
[6.35]
J4
J5
J6
J7
J8
0.25 [6.35] TYP.
(17) PLACES
0.25 [6.35]
0.31
[7.87]
J1
J2
J3
J4
J5
J6
J7
J8
0.31
[7.87]
A
J9
J10 J11 J12 J13 J14 J15 J16
0.50 [12.7] TYP.
TYP. "SMA" FEMALE CONNECTOR
TYP. (17) PLACES
0.50
[12.70]
0.25 [6.35]
TYP. (9) PLACES
TYP. "SMA" FEMALE CONNECTOR
TYP. (9) PLACES
OUTLINE
6
7
8
DIM A
3.5 [88.90]
2.2 [55.88]
1.75 [44.45]
OUTLINE
9
10
DIM A
5.5 [139.70]
2.9 [73.66]
GENERAL NOTES:
1. Dimensions shown in brackets [ ] are in millimeters.
2. Unless specified, all connectors are type SMA female field replaceable.
3. Tolerance as follows:
.xx = ±0.01 [.xx = ±0.25]
.xxx = ±0.005 [.xxx = ±0.13]
