599ST89E Overview

GaAs pHEMT MMIC LNA, 75 Ohm 50 - 1000 MHz

HMC599ST89
/
599ST89E
v02.0311
GaAs pHEMT MMIC LNA, 75 Ohm
50 - 1000 MHz
Features
High p1dB output power: +19 dBm
High output ip3: +39 dBm
low Noise figure: 2.2 dB
Cascadable 75 ohm i/os
single Bias supply: +3V or +5V
industry standard soT89 package
7
Amplifiers - low Noise - smT
Typical Applications
The HmC599sT89(e) is ideal for:
• VHF / UHF Antennas
• HDTV Receivers
• CMTS Equipment
• CATV, Cable Modem & DBS
Functional Diagram
General Description
The HmC599sT89(e) is a GaAs pHemT High
linearity, low Noise Gain Block mmiC smT amplifier
covering 50 to 1000 mHz. packaged in an industry
standard soT89, the amplifier can be used as a
cascadable 75 ohm rf or if gain stage as well
as a pA or lo driver with up to +19 dBm output
power. The HmC599sT89(e) offers 14 dB of gain
with a +39 dBm output ip3 at 250 mHz, and can
operate directly from a +3V or +5V supply. The
HmC599sT89(e) exhibits excellent gain and output
power stability over temperature, while requiring a
minimal number of external bias components.
Electrical Specifications,
Vdd = 5V, T
A
= +25° C
parameter
Gain
Gain Variation over Temperature
input return loss
output return loss
reverse isolation
output power for 1 dB Compression (p1dB)
output Third order intercept (ip3)
(pout= -10 dBm per tone, 1 mHz spacing)
Noise figure
supply Current (idd)
50 - 500 mHz
500 - 1000 mHz
50 - 1000 mHz
50 - 500 mHz
500 - 1000 mHz
50 - 500 mHz
500 - 1000 mHz
50 - 1000 mHz
50 - 500 mHz
50 - 500 mHz
500 - 1000 mHz
50 - 1000 mHz
100
16
min.
13
12
Typ.
14.5
14
0.005
15
12
25
15
20
19
39
36
2.2
120
140
max.
Units
dB
dB
dB/ °C
dB
dB
dB
dB
dB
dBm
dBm
dBm
dB
mA
7-1
For price, delivery and to place orders: Hittite Microwave Corporation, 20 Alpha Road, Chelmsford, MA 01824
Phone: 978-250-3343
Fax: 978-250-3373
Order On-line at www.hittite.com
Application Support: Phone: 978-250-3343 or apps@hittite.com

599ST89E Related Products

599ST89E HMC599ST89 HMC599ST89E
Description GaAs pHEMT MMIC LNA, 75 Ohm 50 - 1000 MHz GaAs pHEMT MMIC LNA, 75 Ohm 50 - 1000 MHz GaAs pHEMT MMIC LNA, 75 Ohm 50 - 1000 MHz
Is it lead-free? - Contains lead Lead free
Is it Rohs certified? - incompatible conform to
Maker - Hittite Microwave(ADI) Hittite Microwave(ADI)
Reach Compliance Code - compli compli
ECCN code - EAR99 EAR99
Other features - LOW NOISE LOW NOISE
Characteristic impedance - 75 Ω 75 Ω
structure - COMPONENT COMPONENT
Gain - 12 dB 12 dB
Maximum input power (CW) - 10 dBm 10 dBm
JESD-609 code - e0 e3
Maximum operating frequency - 960 MHz 960 MHz
Minimum operating frequency - 50 MHz 50 MHz
Maximum operating temperature - 85 °C 85 °C
Minimum operating temperature - -40 °C -40 °C
RF/Microwave Device Types - WIDE BAND LOW POWER WIDE BAND LOW POWER
Terminal surface - Tin/Lead (Sn/Pb) Matte Tin (Sn)
