Revision 2.7
ZK1090-6191-0xxx | EtherCAT cable, PUR, AWG 22,
drag-chain suitable
M12, plug, straight, male, 4-pin, D-coded – RJ45, plug, straight, male, 4-pin
Plugs
Electrical data
Rated voltage
Rated current
Rated impulse voltage
Shielding
Contact resistance
Insulation resistance
Mechanical data
Installation size
Connector type
Configuration
Contact type
Number of positions (face)
Coding
Recommended torque, nut
Mating cycles
Way of locking
Body colour
Body material
Coupling nut material
Seal
Contact carrier colour
Contact carrier material
Contact plating
Contact material
Environmental data
RoHS compliant
Ambient temperature, operation
Protection class
yes
-30...+80 °C, -22...+176 °F
IP 67 in screwed condition (according to IEC 60529)
yes
-40...+85 °C, -40...+185 °F
IP 20
M12
plug
straight
male
4-pin
D-coded
0.6 Nm
≥ 100 (according to IEC 60512-9a)
screw
black
TPU, UL 94
CuZn, Ni
FPM
green
PA, UL 94
Au
CuZn
RJ45
plug
straight
male
4-pin
-
-
≥ 1000
-
black
PC UL 94 V0
-
-
-
-
Ni, Au gal.
CuZn
Head A
250 V
4 A at 40 °C (according to IEC 61076-2-101)
2.5 kV
yes
< 5 mW
-
Head B
160 V (according to IEC 61076-2-101)
1 A at 50 °C
-
yes
-
≥ 10 GΩ (according to IEC 60512-2)
BECKHOFF
New Automation Technology
Page 1 of 4
We reserve the right to make technical changes.
Pollution level
Approvals
3/2 (according to IEC 60664-1)
UL
-
-
Cable
Electrical data
Rated voltage
Operating voltage
Attenuation of shielding
Insulation resistance
Unbalanced capacitance to ground
Mutual capacitance
Characteristic impedance
(Ethernet)
Loop resistance (Ethernet)
Differential impedance (Ethernet)
Unbalanced resistance (Ethernet)
Dielectric strength wire/wire
(Ethernet)
Dielectric strength wire/shield
(Ethernet)
Signal running time (Ethernet)
Electrical parameters (Ethernet)
Test voltage
Mechanical data
Cable structure (Ethernet)
Conductor construction (Ethernet)
Cross section (Ethernet)
Min. bending radius, moved
Min. bending radius, moved in
drag chain
Min. bending radius, fixed
installation
Weight
Outer cable diameter
Conductor material (Ethernet)
Optical covering factor of
shielding (Ethernet)
Use
Max. acceleration
Max. speed
Max. number of cycles
Wall thickness of wire insulation
(Ethernet)
Jacket colour
Material jacket
Wire colour code
Wire insulation material
Printing on the jacket
star quad
7 x 0.25 mm
0.34 mm² (AWG 22)
7.5 x outer cable diameter
15 x outer cable diameter
5 x outer cable diameter
61 kg/km (41.0 lb/1000 ft)
6.5 mm ± 0.2 mm (0.2559" ± 0.0079")
copper, tinned
≥ 85 %
drag-chain suitable
4 m/s²
4 m/s
3 million
0.375 mm
green
PUR (polyurethane)
yellow, orange, white, blue
PP (polypropylene)
BECKHOFF ZB9020 Industrial Ethernet
/ EtherCAT Trailing Cable * CAT5PLUS * 22AWG (SHIELDED) (UL) E119100 CMX 75°C VERIFIED (UL) CAT 5E PATCH CABLE
FRNC *"length in meters"
black
-40…+70 °C, -40…+158 °F
-20…+60 °C, -4…+140 °F
yes
according to DIN EN 60811-404 (7x24 h/90 °C)
depends on medium, concentration, temperature and duration
yes
yes
yes
yes
yes
UL-Style AWM 20963
600 V
≤ 125 V (peak value, not for high voltage purposes)
≥ 40 dB
≥ 500 MΩ/km
1600 pF/km
52 nF/km (1 kHz)
100
W
±15
W
(100 MHz)
≤ 115
W/km
250
W/km
2%
1000 V DC/700 V AC
1000 V DC/700 V AC
5.3 ns/m
based on CAT 5
≥ 2000 V
Printing colour
Environmental data
Operation temperature range,
moved
Operation temperature range,
fixed installation
UV resistance
Oil resistance
Acid, lye and solvent resistance
LABS-free
Flame-retardant
CFC-free
Halogen-free
Silicone-free
Approvals
BECKHOFF
New Automation Technology
Page 2 of 4
We reserve the right to make technical changes.
Attenuation
Max. insertion loss
Frequency [MHz]
[db/100 m]
[db/100 ft]
Min. near-end crosstalk attenuation
Frequency [MHz]
[db/100 m]
[db/100 ft]
1
80
24.4
4
76.0
23.2
10
70.0
21.3
16
65.0
19.8
20
63.0
19.2
31.25
60.0
18.3
62.5
55.0
16.8
100
50.0
15.2
1
2.1
0.6
4
4.0
1.2
10
6.3
1.9
16
8.0
2.4
20
9.0
2.7
31.25
11.4
3.5
62.5
16.5
5
100
21.3
6.5
Contact assembly
Dimensions
A1
A2
B1
49.00 mm
20.00 mm
55.00 mm
Notes
- Depending on the cable length (L), the following length tolerances apply:
0 m…<0.2 m: ± 10 mm | 0.2…4.0 m: + 40 mm | ≥ 4.0 m: + 1 %
- Illustrations similar
- Further cable length on request. The last three digits of the ordering information is the cable length in decimeters, e.g.ZKxxxx-xxxx-x020 = cable length
2.00 m
BECKHOFF
New Automation Technology
Page 3 of 4
We reserve the right to make technical changes.
Ordering information
ZK1090-6191-0002
ZK1090-6191-0005
ZK1090-6191-0010
ZK1090-6191-0020
ZK1090-6191-0025
ZK1090-6191-0030
ZK1090-6191-0040
ZK1090-6191-0045
ZK1090-6191-0050
ZK1090-6191-0060
ZK1090-6191-0070
ZK1090-6191-0075
ZK1090-6191-0100
ZK1090-6191-0110
ZK1090-6191-0120
ZK1090-6191-0130
ZK1090-6191-0150
ZK1090-6191-0180
ZK1090-6191-0200
ZK1090-6191-0250
ZK1090-6191-0300
ZK1090-6191-0350
ZK1090-6191-0400
ZK1090-6191-0500
ZK1090-6191-0600
ZK1090-6191-0700
ZK1090-6191-0999
Length
0.20 m
0.50 m
1.00 m
2.00 m
2.50 m
3.00 m
4.00 m
4.50 m
5.00 m
6.00 m
7.00 m
7.50 m
10.00 m
11.00 m
12.00 m
13.00 m
15.00 m
18.00 m
20.00 m
25.00 m
30.00 m
35.00 m
40.00 m
50.00 m
60.00 m
70.00 m
100.00 m
Beckhoff
®
, TwinCAT
®
, EtherCAT
®
, EtherCAT P
®
, Safety over EtherCAT
®
, TwinSAFE
®
, XFC
®
and XTS
®
are registered trademarks of and licensed by Beckhoff Automation GmbH. Other designations used in this publication may be
trademarks whose use by third parties for their own purposes could violate the rights of the owners.
© Beckhoff Automation GmbH & Co. KG 05/2019
The information provided in this brochure contains merely general descriptions or characteristics of performance which in case of actual application do not always apply as described or which may change as a result of further
development of the products. An obligation to provide the respective characteristics shall only exist if expressively agreed in the terms of contract.
BECKHOFF
New Automation Technology
Page 4 of 4
We reserve the right to make technical changes.
