1:1 Turns Ratios for Different Gigabit Transceivers IC
Compliant with IEEE802.3 standard including
S
CHEMATICS
350uH OCL with 8mA DC bias
Enhanced crosstalk and return loss performance
Support 4 pairs of Category 5 UTP cable with
1000Base-T full duplex applications
Design to withstand IR-reflow with peak
temperature per IPC/JEDEC J-STD-020C
Operating temperature 0°C to +70°C.
RoHS compliant versions are available
E
LECTRICAL
S
PECIFICATION @
25°C
Part
Number
RoHS
Part
Number
Insertion
Loss
(dB Max)
.1-100MHz 1-30MHz
824-M0167 824-00167R
824-M0168 824-M0168R
824-M0265
824-M0272
1
1
2
2
Return Loss
(dB Min)
40MHz
14.4
14.4
14.4
14.4
14.4
14.4
50MHz
13.1
13.1
13.1
13.1
13.1
13.1
CMRR
(dB Min)
60-80MHz .1-100MHz
12.0
12.0
12.0
12.0
12.0
12.0
35.0
35.0
33.0
-
30.0
30.0
30MHz
45.0
43.5
33.0
30.0
43.5
43.5
Crosstalk
(dB Min)
60MHz
40.0
37.5
33.0
30.0
37.5
37.5
100MHz
35.0
33.0
33.0
30.0
33.0
33.0
Hipot
(Vrms)
1.0
1.0
1.4
1.0
1.0
1.0
16.0
16.0
16.0
16.0
16.0
16.0
1500
1500
1500
1500
1500
1500
-
-
824-M0329 824-M0329R
824-M0331 824-M0331R
1
Notes:
1. Operating temperature -40°C to +85°C.
2. Contact EEMPL for RoHS compliant versions availability.
M
ECHANICAL
D
IMENSIONS
Package: SO048C / SO048F
5
1.100 MAX
27.94
.075
1.91
.920
23.37
.040
1.02
.600±.010
15.24 ±0.25
824-M0xxx
(DATE) (COUNTRY)
.635
16.13
.025
0.64
Recommended
Pad Layout
.480 MAX
12.19
.005-.015
0.13-0.38
.275 MAX
6.99
REFERENCE OR
GAUGE PLANE
.040±.005
1.02±0.13
.035±.010
0.89±0.25
.920±.010
23.37±0.25
0-8°
Notes:
Weight (in gram)
:
4.6 typ.
Tape & Reel
:
300 / reel
3. All dimensions are specified in inches with higher precedence in inches.
mm
4. Unless otherwise specified, all tolerances are ± .010 .
0.25
5. For available RoHS part number, the part will be marked with “824-M0xxxR” or “824-00xxxR, instead of “824-M0xxx”.
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
1
Tel: (852) 2765 3888
Fax: (852) 2954 3304
EH105(06)
Revised in 06/07
E & E Magnetic Products Limited
1000 Base-T Dual Port
Magnetic Module
1:1 Turns Ratios for Different Gigabit Transceivers IC
S
CHEMATICS
824-M0167
LINE SIDE (Secondary)
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
CHIP SIDE (Primary)
S
CHEMATICS
S
CHEMATICS
824-M0168 / 824-M0265
LINE SIDE (Secondary)
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
1
2
3
4
5
6
7
8
9
10
11
CH1
CH2
CH3
CH4
S
CHEMATICS
12
13
14
15
16
17
18
19
20
21
22
23
24
CH5
CH6
CH7
CH8
CHIP SIDE (Primary)
S
CHEMATICS
824-M0272
LINE SIDE (Secondary)
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
CHIP SIDE (Primary)
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
2
Tel: (852) 2765 3888
Fax: (852) 2954 3304
EH105(06)
Revised in 06/07
E & E Magnetic Products Limited
1000 Base-T Dual Port
Magnetic Module
1:1 Turns Ratios for Different Gigabit Transceivers IC
S
CHEMATICS
824-M0329 / 824-M0331
48
47
46
45
44
43
42
41
40
Line Side (Secondary)
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Chip Side (Primary)
FOR MORE INFORMATION, PLEASE CONTACT
HEADQUARTER
2/F Block A, Merit Industrial Centre,
94 Tokwawan Road, Kowloon,
Hong Kong
Tel: (852) 2765 3888
Fax: (852) 2954 3304
Email: eempl@eleceltek.com
Website: http://www.eleceltek.com
Information herein is for reference only and subject to change without notice. It does not constitute any representation, warranty or commitment of the company in respect
of the products in any aspect. All logos, brands and product names mentioned herein are trademarks or registered trademarks of their respective owners. The company
does not assume any liability arising out of the application or use of any product or circuit described herein. Copyrights 2006, E & E Magnetic Products Limited.
