Wire-wound Chip Inductors- Molded
ctparts.com
CTHC2220 Series
From 1.0 µH to 1,000 µH
Part
Number
CTHC2220_-1R0_
CTHC2220_-1R2_
CTHC2220_-1R5_
CTHC2220_-1R8_
CTHC2220_-2R2_
CTHC2220_-2R7_
CTHC2220_-3R3_
CTHC2220_-3R9_
CTHC2220_-4R7_
CTHC2220_-5R6_
CTHC2220_-6R8_
CTHC2220_-8R2_
CTHC2220_-100_
CTHC2220_-120_
CTHC2220_-150_
CTHC2220_-180_
CTHC2220_-220_
CTHC2220_-270_
CTHC2220_-330_
CTHC2220_-390_
CTHC2220_-470_
CTHC2220_-560_
CTHC2220_-680_
CTHC2220_-820_
CTHC2220_-101_
CTHC2220_-121_
CTHC2220_-151_
CTHC2220_-181_
CTHC2220_-221_
CTHC2220_-271_
CTHC2220_-331_
CTHC2220_-391_
CTHC2220_-471_
CTHC2220_-561_
CTHC2220_-681_
CTHC2220_-821_
CTHC2220_-102_
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CTHC2220-1R0_
J = ±5%, K = ±10%
CTHC2220F
Please specify “F” for RoHS compliant
Inductance
(µH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
L Test
Freq.
(MHz)
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.252
Q
Fact.
Min.
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
20
20
20
20
20
20
20
20
20
20
20
20
20
Q Test
Freq.
(MHz)
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.252
SRF
Min.
(MHz)
95
70
55
47
42
37
34
32
29
26
24
22
19
17
16
14
13
12
11
9.5
8.5
7.8
7.0
6.4
6.0
5.4
4.8
4.4
3.9
3.6
3.2
2.9
2.6
2.4
2.2
2.0
1.8
DCR
Max.
Ω
(Ω)
0.03
0.04
0.04
0.05
0.06
0.07
0.08
0.09
0.11
0.13
0.15
0.18
0.21
0.25
0.30
0.36
0.43
0.52
0.62
0.72
0.85
1.00
1.20
1.40
1.60
1.90
2.20
2.80
3.40
4.20
4.90
5.80
7.00
8.50
10.0
13.0
15.0
Rated
DC
(mA)
1800
1700
1600
1400
1300
1200
1120
1050
950
880
810
750
690
630
580
530
480
440
400
370
340
310
290
270
250
230
210
190
170
155
140
130
120
110
100
90
85
CHARACTERISTICS
Description:
Ferrite core, wire-wound molded chip inductor
Applications:
TV’s, VCR’s, disk drives, computer peripherals,
telecommunication devices and electronic control boards
for automobiles
Operating Temperature:
-25°C to +85°C
Inductance Tolerance:
±5% & ±10%
Testing:
Inductance and Q are tested on an HP4285A at
specified frequency
Packaging:
Tape & Reel
Part Marking:
Inductance code or inductance code plus
tolerance.
Miscellaneous:
RoHS Compliant available.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
5.8±0.3
0.23±0.011
B
5.2±0.3
0.20±0.011
C
5.2±0.3
0.20±0.011
D
1.8
0.07
E
1.3±0.2
0.05±0.008
05.31.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
