Data Sheet
SML-P24 Series
PICOLED™-Duo
1010 0404）
（
1.0×1.0mm
（t=0.2mm）
Features
・
Ultra compact 2-color type LED 1.0×1.0
・
Thinnest in the world
＊
t=0.2mm
・
Low height contributes to the improvement of color mixture
＊Investigated
Aug. 2009
Color
Type
M U
Specifications
Part No.
Absolute Maximum Ratings (Ta＝25℃)
Electrical and Optical Characteristics (Ta＝25℃)
Chip
Emitting Power
Forward Voltage V
F
Reverse Current I
R
Dominant Wavelength
λD
Luminous Intensity I
V
Forward Peak Forward Reverse Operating
Storage
Structure Color Dissipation Current
Current
Voltage Temperature Temperature
Max.
Min.*
2
Typ. Max.*
2
Min. Typ.
P
D
(mW) I
F
(mA) I
FP
(mA) V
R
(V)
Topr(℃)
Tstg(℃) Typ.(V) I
F
(mA) (μA) V
R
(V) (nm) (nm) (nm) I
F
(mA) (mcd) (mcd) I
F
(mA)
AIGaInP
on GaAs
Green
Red
54
52
20
100
*1
5
-40 to +85
-40 to +100
2.2
2.1
20
100
4
569
615
572
620
575
625
20
10
25
21
52
20
■■
SML-P24MUW
＊1:Duty1/10,
1kHz
＊2:Reference
Dimensions
1
0.6
①
1
③
Cathode mark
④
(0.08)
Recommended Solder Pattern Viewing Angle
SML-P24 Series
X-Y
M
U
ANGULAR DISPLACEMENT(deg)
Directivity (deg)
30°
40°
50°
60°
20°
10°
0°
10°
20°
30°
40°
50°
X’ - Y’
G
R
M
U
60°
70°
80°
ANGULAR DISPLACEMENT(deg)
Directivity (deg)
30°
40°
50°
60°
70°
80°
20°
10°
0°
10°
20°
30°
40°
M, U
50°
60°
70°
80°
②
0.5
0.3
0.5
70°
80°
90°
100
0.2
+0.05
-0.02
0.3
GREEN
①
②
RED
③
④
0.3
0.31
Tolerance :
±0.1
（unit
: mm）
（unit
: mm）
＊PICOLED
TM
is ROHM's pending trademark.
© 2010 ROHM Co., Ltd. All rights reserved.
www.rohm.com
1/3
0.5
Cathode mark
0.3
RELATIVE INTENSITY(%)
RELATIVE INTENSITY (%)
50
0
50
90°
100
M
U
90°
100
RELATIVE INTENSITY(%)
RELATIVE INTENSITY (%)
50
0
50
90°
100
0.5
2010.06 - Rev.A
SML-P24 Series
Rank Reference of Brightness
SML-P24MUW
Package
size
(mm)
Height
(mm)
（Ta=25˚C,
I
F
＝20mA）
K
L
M
N
P
Q
R
S
T
U
(mcd)
4.0 to 6.3 6.3 to 10 10 to 16 16 to 25 25 to 40 40 to 63 63 to 100 90 to 140 140 to 220 220 to 360
Emitting Color
Luminous
Intensity
Mini-mold 1010
Chip LEDs
0.2
Red
Yellowish Green
U
M
Part No. Construction
∗
“−” will be taken out for
emitting color B series.
S M L
Series name
P 2 4
Package name
Chip Type
M U W
Emitting Color
Resin Color
T 8 6
Taping Specifications
N P
Rank sign (Brightness Rank)
∗
2
4
Standard Type
High Brightness Type
M
Yellowish-Green:572nm
B
Blue:470nm
U
Red:620nm
W
MilkyWhite
T86
Cathode at sprocket hole side
T87
Reverse of T86
∗
Concerning the Brightness rank
• Please refer to the rank chart above for luminous intensity classification.
• Part name is individual for each rank.
• When shipped as sample, the part name will be a representative part name.
General products are free of ranks. Please contact sales if rank appointment is needed.
Packing Specification
ROHM LED products are being shipped with desiccant (silica gel) concluded in moisture-proof bags.
Pasting the moisture sensitive label on the outer surface of the moisture-proof bags or enclosing the humidity indication card inside the bag is available upon request.
Please contact the nearest sales office or distributer if necessary.
© 2010 ROHM Co., Ltd. All rights reserved.
www.rohm.com
3/3
2010.06 - Rev.A
