EWSO1851 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> oscillator> EWSO1851

Preview

EWSO1851: DescriptionVoltage Controlled Oscillator, 1500MHz Min, 1885MHz Max; CategoryPassive components oscillator; File Size36KB，1 Pages; ManufacturerThales Components Corp.

Download Datasheet Parametric View All

EWSO1851 Overview

Voltage Controlled Oscillator, 1500MHz Min, 1885MHz Max

EWSO1851 Parametric

Parameter Name	Attribute value
Maker	Thales Components Corp.
Reach Compliance Code	unknown
Maximum control voltage	18 V
Minimum control voltage	5 V
Modulation sensitivity	50 MHz/V
offset frequency	20 kHz
Maximum operating frequency	1885 MHz
Minimum operating frequency	1500 MHz
Oscillator type	VOLTAGE CONTROLLED OSCILLATOR
Output Power	7 dBm
phase noise	-107 dBc/Hz
Maximum slew rate	35 mA
Nominal supply voltage	8 V

Preview

Download Datasheet

View All

THALES MICROSONICS

EW SO 1851

VCO - Voltage Controlled Oscillator

CABLE MODEM

Specification

Minimum

FREQUENCY RANGE

TEMPERATURE RANGE

MHz

°C

dBm

V

MHz/V

dBC/Hz

MHz/V

MHz

V

mA

dBc

0

–55

5

2

1500

Typical

Maximum

1885

+80

+125

Notes

5

3

4

5

1-5

3-4

3

5

Comments

VCO

Operating

Storage

POWER OUTPUT (versus all causes)

CONTROL VOLTAGE

CONTROL VOLTAGE SENSITIVITY

PHASE NOISE

Offset: 20 KHz

PUSHING

PULLING VSWR 1.6: 1

POWER SUPPLY

Voltage

Current

HARMONICS H2, H3

Notes:

1.

2.

3.

4.

5.

7

9

18

50

–107

±3

2

Peak to peak value

± 5%

THALES MICROSONICS reserves the right to modify herein specifications and information at any time when necessary to provide optimum performance and cost.

8

35

–15

5

4

Control voltage sensitivity = Fmax - Fmin / (V

Fmax

- V

Fmin

).

Return loss dB; value pk - pk.

Parameter guaranteed by periodical qualification.

Parameter guaranteed by design and characterization.

Parameter tested at 100 %.

120
