SMV4596B-LF
PHASE NOISE (1 Hz BW, typical)
14118 Stowe Drive, Suite B | Poway, CA 92064
TEL: (858) 621-2700 | FAX: (858) 486-1927
URL: www.zcomm.com
EMAIL: applications@zcomm.com
Rev B2
Applications
•
Microwave Radio
•
Clock Generators
•
Application Notes
• AN-101: Mounting and Grounding
• AN-102: Output Loading
• AN-107: Manual Soldering
£(f) (dBc/Hz)
Voltage-Controlled Oscillator
Surface Mount Module
OFFSET (Hz)
Performance Specifications
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW)
Harmonic Suppression (2nd)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance
Pushing
Pulling (20. dB Return Loss, Any Phase)
Operating Temperature Range
Package Style
Power Supply Requirements
Supply Voltage (Vcc, nom.)
Supply Current (Icc)
Additional Notes
Min
4595
Typ
Max
4598
Units
MHz
dBc/Hz
dBc
Vdc
MHz/V
dBm
pF
MHz/V
MHz
°C
-81
-25
0
110
-3
-1
50
50
5
8
-40
SUB-L
Min
Typ
2.8
8
10
Max
85
1
-20
2.5
Units
Vdc
mA
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 1 of 2
FRM-S-002 B
Voltage-Controlled Oscillator
Surface Mount Module
Tuning Curve, typ.
4660
4630
SMV4596B-LF
Rev B2
FREQUENCY (MHz)
4600
4570
4540
4510
4480
4450
4420
4390
4360
4330
4300
0
0.5
1
1.5
2
2.5
85 °C
25 °C
-40 °C
TUNING VOLTAGE (Vdc)
Power Curve, typ.
Footprint
POWER OUTPUT (dBm)
4
3
2
1
0
-1
-2
-3
-4
4351
RECOMMENDED FOOTPRINT
SEVERAL HOLES OF O0.015 ON
GND. PLANE ARE RECOMMENDED
FOR GOOD GROUNDING.
0.030 MIN. CUTBACK
FROM LIVE PADS
4415
4469
4526
4581
4642
FREQUENCY (MHz)
85 °C
25 °C
-40 °C
Physical Dimensions
PIN CONFIGURATION
Z-COMM
XXXXXXXX-LF
W/O#
D/C
P1
P2
P3
REST
Vt
RF Out
Vcc
GROUND
PACKAGE
SUB MINI
SUB MINI-L
H
0.110
0.080
NOTE: ALL DIMENSIONS ARE IN INCHES
TOL: XXX: +/- 0.010
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 2 of 2
FRM-S-002 B
