Front Mount-The connector is mounted in front of the panel.
Rear Mount-The connector is mounted behind the panel.
Panel Cutout
A1
B1
10° 0° Typ
R .032 Max. Typ
[ 0.81 ]
.120
[ 3.05 ]
F1
E1
.060
[ 1.52 ]
Full Radius
D1
C1
Alternate
GI Radius
Typ
Mounting Styles
Standard
.12
[ 3.0 ]
Dia
Through Hole
Strain Relief
(Order Separately)
Material: Stainless Steel
.07 Max
[ 1.78 ]
Threaded Inserts
F
#4-40 UNC
+.000
.242 -.010
[ 6.15 ]
.12
[ 3.0 ]
.06
[ 1.5 ]
.16
[ 4.06 ]
TS-0235-E
Sheet 3 of 3
