Compact Thick Film Chip Resistors
MCR10 (0805 size)
Features
1) Power rating of 1 / 8W (tolerance J,F)
2) Highly reliable chip resistor
Ruthenium oxide dielectric offers superior resistance to the elements.
3) Electrodes not corroded by soldering
Thick film makes the electrodes very strong.
4) Leading the world in development and mass production.
Since start of production in 1982 (first in the wold), this component has established a solid reputation as a general–purpose
chip resistor.
5) ROHM resistors have approved ISO9001- / ISO/TS 16949- certification.
Ratings
Design and specifications are subject to change without notice. Carefully check the specification sheet before using or ordering
it.
Item
Rated power
Conditions
Power must be derated according to the power derating curve
in Figure 1 when ambient temperature exceeds 70°C.
100
80
POWER LOAD (%)
Specifications
J, F
D
0.125W (1 / 8W)
at 70°C
0.1W (1 / 10W)
at 70°C
60
40
20
0
−55
0
70
100
155
AMBIENT TEMPERATURE (
°
C)
Fig.1
Rated voltage
The voltage rating is calculated by the following equation.
If the value obtained exceeds the limiting element voltage,
the voltage rating is equal to the maximum operating voltage.
E: Rated voltage (V)
E= P×R
P: Rated power (W)
R: Nominal resistance (Ω)
Nominal resistance
Operating temperature
See Table 1.
−55°
C to
+ 155°C
Limiting element voltage
150V
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
1/3
2011.06 - Rev.H
MCR10 (0805 size)
Jumper type
Resistance
Rated current
Operating temperature
Max. 50mΩ
2A
−55°C
to
+155°C
Data Sheet
Table 1
Resistance tolerance
D (±0.5%)
Resistance range
(Ω)
Resistance temperature coefficient
(ppm/°C)
10 to 91
100 to 1M
10 to 2.2M
1.0 to 9.1
10 to 10M
(E24)
(E24)
(E24,96)
(E24)
(E24)
±100
±50
±100
±400
±200
F (±1%)
J (±5%)
Characteristics
Item
Guaranteed value
Resistor type
Jumper type
J :
±5%
F :
±1%
D :
±0.5%
Max. 50mΩ
Test conditions (JIS C 5201-1)
JIS C 5201-1 4.5
Resistance
Variation of resistance
with temperature
Overload
See Table.1
±
(2.0%+0.1Ω)
JIS C 5201-1 4.8
Measurement :
+25
/
+125°C
JIS C 5201-1 4.13
Rated voltage (current)
×2.5,
2s.
Limiting element voltage
×2
: 300V
JIS C 5201-1 4.17
Rosin·Ethanol (25%WT)
Soldering condition : 235±5°C
Duration of immersion : 2.0±0.5s.
JIS C 5201-1 4.18
Soldering condition : 260±5°C
Duration of immersion : 10±1s.
JIS C 5201-1 4.19
Test temp. :
−55°C
to
+125°C
5cyc
JIS C 5201-1 4.24
40°C, 93%RH
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.1
Rated voltage (current), 70°C
1.5h : ON
−
0.5h : OFF
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.3
155°C
Test time : 1,000h to 1,048h
JIS C 5201-1 4.29
23±5°C, Immersion cleaning, 5±0.5min.
Solvent : 2-propanol
JIS C 5201-1 4.33
Max. 50mΩ
Solderability
A new uniform coating of minimum of
95% of the surface being immersed
and no soldering damage.
±
(1.0%+0.05Ω)
Max. 50mΩ
No remarkable abnormality on the appearance.
±
(1.0%+0.05Ω)
±
(3.0%+0.1Ω)
Max. 50mΩ
Max. 100mΩ
Resistance to
soldering heat
Rapid change of
temperature
Damp heat, steady state
±
(3.0%+0.1Ω)
Endurance at 70°C
±
(3.0%+0.1Ω)
Endurance
±
(1.0%+0.05Ω)
Resistance to solvent
Max. 100mΩ
Max. 100mΩ
Max. 50mΩ
Bend strength of
the end face plating
Max. 50mΩ
±
(1.0%+0.05Ω)
Without mechanical damage such as breaks.
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
2/3
2011.06 - Rev.H
