DRA/DRS Series T1
Right Angle LED Bar*
Special Features
*Patented
• Bilevel design saves PC board space
• Customized to your specifications without tooling charges
Variable LED spacing, minimum .170˝, maximum bar length 6˝
Variable color sequence
• Shrouded version available for backlighting
• Bar provides consistent alignment for multiple LED mounting
• Available with a variety of LEDs
• Bottom standoff facilitates board washing
• Wave solderable and chemically cleanable
• Housing and bar material UL 94V-0 rated
3mm PC Board Mount LEDs
Electrical and Optical Characteristics (TA=25°C)
LED
Part#
Color
Luminous
Intensity (mcd)
Typ.@IF(mA)
VF Typ.@IF (mA)
Viewing
Angle
2Θ
2
Peak
More
Wavelength LED Data
(mm)
Page#
Package Dimensions
.330
(8.4)
.125 REF
(3.2)
.200
(5.0)
.100 (2.5)
.100
(2.5)
.175
(4.4)
CATHODE LEAD (TYP.)
(Red/Yellow cathode
for bicolor)
.170 TYP.
(4.3)
.120 DIA.
(3.0)
.400 REF (10.2)
.024 REF
(0.6)
.100
(2.5)
WITH SHROUD
6.0 MAX
(152.4)
.170 MIN
(4.3)
HIGH EFFICIENCY
1300
1301
1302
1313
Yellow
Red
Green
Orange
6.0
5.5
5.0
5.5
10
10
10
10
2.0
1.9
2.1
1.9
10
10
10
10
60°
60°
60°
60°
583
635
565
600
21
21
21
21
.430 MAX
(10.9)
LOW CURRENT
1303
1304
1305
Red
Yellow
Green
2.1
1.6
2.1
2
2
2
1.8
1.9
1.8
2
2
2
50°
50°
50°
635
583
565
22
22
22
5V INTERNAL RESISTOR
1307
1308
1309
Red
Yellow
Green
8.0
8.0
8.0
10
10
10
5.0
5.0
5.0
10
10
10
60°
60°
60°
635
583
565
23
23
23
.135 MIN (3.4)
.100 (2.5)
BLUE
8310
8311
Blue
Blue
25.0
55.0
20
20
4.5
4.5
20
20
60°
20°
430
430
30
30
All Dimensions are in inches (mm)
Standard Polarity shown in drawing: Cathode right
BICOLOR
8901
8903
Red
Green
Yellow
Green
20.0
20.0
10.0
20.0
20
20
20
20
2.0
2.2
2.1
2.2
20
20
20
20
60°
60°
625
565
590
565
27
27
How To Order
MULTIPLE DRA/DRS LEDs ON A BAR
ULTRA BRIGHT
1310
1311
1312
1315
Red
Yellow
Green
Red
45.0
45.0
45.0
45.0
20
20
20
20
1.9
2.1
2.2
1.8
20
20
20
20
45°
45°
45°
60°
635
583
565
645
21
21
21
21
x — DR x — x x x x — x x x x — x x x
# of Modules
Per Bar
Standard = A
Shrouded = S
Top Pos.
See LED Lamp
Chart for Part #
(use MCOO for
multiple colors)
Bottom Pos.
See LED Lamp
Chart for Part #
(use MCOO for
multiple colors)
Center to Center
spacing of LEDs
in inches
(If spacing varies,
use SPL)
INDIVIDUAL DRA/DRS LEDs
SUPER ULTRA BRIGHT
8306
8312
8313
Green
Yellow
Red
200.0
700.0
800.0
20
20
20
2.2
2.0
1.85
20
20
20
50°
50°
50°
565
595
660
29
29
29
DR X — X X X X — X X X X
Standard = A
Shrouded = S
Top Pos.
See LED
Lamp Chart
for Part #
Bottom Pos.
See LED
Lamp Chart
for Part #
Note: Consult factory if your color sequence and/or spacing varies.
®
WILBRECHT
ELECTRONICS, INC.
1400 Energy Park Drive, Suite 18 • St. Paul, MN 55108-5248 • (651) 659-0919 • FAX (651) 659-9204 • www.wilbrecht.com
LEDCO
DIVISION
11
