PMCIR-106-03-A-B-8

Description
Circulator, 1059nm Min, 1069nm Max, LC/SPC Connector
CategoryWireless rf/communication    Optical fiber
File Size200KB,1 Pages
ManufacturerLightel Technologies Inc.
Download Datasheet Parametric View All

PMCIR-106-03-A-B-8 Overview

Circulator, 1059nm Min, 1069nm Max, LC/SPC Connector

PMCIR-106-03-A-B-8 Parametric

Parameter NameAttribute value
MakerLightel Technologies Inc.
Reach Compliance Codeunknown
Connection TypeLC/SPC CONNECTOR
Fiber optic equipment typesCIRCULATOR
Fiber typePMF
Maximum insertion loss2.1 dB
Minimum isolation25 dB
Maximum operating temperature65 °C
Minimum operating temperature
Maximum operating wavelength1069 nm
Minimum operating wavelength1059 nm
Nominal operating wavelength1064 nm
Maximum optical input power300 mW
minimum return loss50 dB
Circulator
1064nm Three-port Polarization Maintaining Circulator
Parameter
Operating Wavelength Range
Insertion Loss
Isolation
Extinction Ratio
Return Loss
Cross Talk
Polarization Alignment
Maximum Power
Fiber Tensile Load
Operating Temperature
Storage Temperature
Package Dimensions
Note1: All values specified are without connectors.
Note2: Higher performance specifications upon request.
Note3: Fiber type: PM 980 250
µ
m Panda fiber
1059-1069 nm
≤ 2.1 dB
≥ 25 dB
≥ 20 dB
≥ 50 dB
≥ 45 dB
Slow Axis
300 mW
5N
0° C ~ + 65° C
- 40° C ~ + 85° C
5.5 mm (Φ x 35 mm (L)
P M C I R-
- 0 3 -
Center Wavelength
106: 1064 nm
03: 3 ports
A -
Fiber Length
A: 1 meter
-
Pigtail Style
(=Package style)
B: bare fiber
L: 900
µm
loose tube
Connector
0: None
1: FC/PC
2: FC/APC
3: SC/ PC
4: SC/APC
5: FC/SPC
6: SC/SPC
7: LC/UPC
8: LC/SPC
9: Special
A: FC/UPC
B: SC/UPC
C: ST
www.lighteltech.com
2210 Lind Ave SW, Suite 100
Renton, WA 98057 USA
(425) 277-8000 ph.
(425) 277-5280 Fax
All rights Reserved 2009
