300SP-1(J1GRY)M7QE

Description
Rocker Switch, SPDT, On-on, 5A, 28VDC, 5 PCB Hole Cnt, Solder Terminal, Rocker Actuator, Through Hole-right Angle,
CategoryMechanical and electronic products    switch
File Size31KB,1 Pages
ManufacturerE-Switch
Websitehttp://www.e-switch.com
Download Datasheet Parametric View All

300SP-1(J1GRY)M7QE Overview

Rocker Switch, SPDT, On-on, 5A, 28VDC, 5 PCB Hole Cnt, Solder Terminal, Rocker Actuator, Through Hole-right Angle,

300SP-1(J1GRY)M7QE Parametric

Parameter NameAttribute value
MakerE-Switch
Reach Compliance Codecompliant
ECCN codeEAR99
Actuator angle25 deg
Actuator colorGRAY
Actuator length0.548 inch
Actuator typeROCKER
body height20.32 mm
Body length or diameter6.858 mm
center contact materialCOPPER ALLOY
Center contact platingSILVER
Contact (AC) maximum rated R load2A@250VAC
Maximum contact current (AC)2 A
Maximum contact current (DC)5 A
Contact (DC) maximum rated R load5A@28VDC
Contact functionON-ON
Contact resistance0.01 mΩ
Maximum contact voltage (AC)250 V
Maximum contact voltage (DC)28 V
Dielectric withstand voltage1000VRMS V
Electrical life50000 Cycle(s)
Insulation resistance1000000000 Ω
Manufacturer's serial number300SP-1(J1GRY)M7QE
Installation featuresTHROUGH HOLE-RIGHT ANGLE
Maximum operating temperature85 °C
Minimum operating temperature-30 °C
PCB hole count5
sealEPOXY
surface mountNO
switch functionSPDT
Switch typeROCKER SWITCH
Terminal length0.125 inch
Terminal materialCOPPER ALLOY
Termination typeSOLDER
