EMRE12F2H-173.3705M
REGULATORY COMPLIANCE
2011/65 +
2015/863
(Data Sheet downloaded on Sep 23, 2020)
191 SVHC
ITEM DESCRIPTION
MEMS Clock Oscillators LVDS (DS) 2.5Vdc 6 Pad 5.0mm x 7.0mm Plastic Surface Mount (SMD) 173.3705MHz ±20ppm over 0°C
to +70°C
ELECTRICAL SPECIFICATIONS
Nominal Frequency
Frequency Tolerance/Stability
173.3705MHz
±20ppm Maximum over 0°C to +70°C (Inclusive of all conditions: Calibration Tolerance at 25°C, Frequency Stability
over the Operating Temperature Range, Supply Voltage Change, Output Load Change, 1st Year Aging at 25°C,
Reflow, Shock, and Vibration)
±1ppm Maximum First Year
2.5Vdc ±10%
45mA Typical, 55mA Maximum (Excluding Load Termination Current)
50mVdc Maximum
200mVdc Minimum, 350mVdc Typical, 500mVdc Maximum
1.125V Minimum, 1.20V Typical, 1.375V Maximum
500pSec Typical, 600pSec Maximum (Measured over 20% to 80% of waveform)
50 ±5(%) (Measured at 50% of waveform)
50mVdc Maximum
100 Ohms Between Output and Complementary Output
LVDS
Output Enable (OE) and Complementary Output
Vih of 70% of Vdd Minimum or No Connect to Enable Output and Complementary Output, Vil of 30% of Vdd Maximum
to Disable Output and Complementary Output (High Impedance)
35mA Maximum (OE) Without Load
0.5pSec Typical, 1pSec Maximum (Fj = 12kHz to 20MHz; Random)
0.2pSec Typical
1.0pSec Typical
1.4pSec Typical, 1.7pSec Maximum
15pSec Typical, 20pSec Maximum
10mSec Maximum
-55°C to +125°C
Aging at 25°C
Supply Voltage
Input Current
Differential Output Error (dVod)
Differential Output Voltage (Vod)
Offset Voltage (Vos)
Rise/Fall Time
Duty Cycle
Offset Error (dVos)
Load Drive Capability
Output Logic Type
Logic Control / Additional Output
Output Control Input Voltage
Output Enable Current
RMS Phase Jitter
Period Jitter (Deterministic)
Period Jitter (Random)
Period Jitter (RMS)
Period Jitter (pk-pk)
Start Up Time
Storage Temperature Range
ENVIRONMENTAL & MECHANICAL SPECIFICATIONS
ESD Susceptibility
Flammability
Mechanical Shock
Moisture Resistance
Moisture Sensitivity Level
Resistance to Soldering Heat
Resistance to Solvents
Solderability
Temperature Cycling
Thermal Shock
Vibration
MIL-STD-883, Method 3015, Class 2, HBM 2000V
UL94-V0
MIL-STD-883, Method 2002, Condition G, 30,000G
MIL-STD-883, Method 1004
J-STD-020, MSL 1
MIL-STD-202, Method 210, Condition K
MIL-STD-202, Method 215
MIL-STD-883, Method 2003 (Six I/O Pads on bottom of package only)
MIL-STD-883, Method 1010, Condition B
MIL-STD-883, Method 1011, Condition B
MIL-STD-883, Method 2007, Condition A, 20G
www.ecliptek.com | Specification Subject to Change Without Notice | Revision A 05/11/2012 | Page 1 of 6
Ecliptek, LLC
5458 Louie Lane, Reno, NV 89511
1-800-ECLIPTEK or 714.433.1200
EMRE12F2H-173.3705M
Test Circuit for Tri-State and Complementary Output
Oscilloscope
Frequency
Counter
Current
Meter
0.01µF
(Note 1)
Supply
Voltage
(V
DD
)
Probe 2
(Note 2)
Probe 1
(Note 2)
100 Ohms
Complementary
Output
Output
Switch
0.1µF
(Note 1)
Ground
Power
Supply
Voltage
Meter
Power
Supply
Tri-State
No
Connect
Note 1: An external 0.01µF ceramic bypass capacitor in parallel with a 0.1µF high frequency ceramic bypass capacitor close (less than 2mm)
to the package ground and supply voltage pin is required.
Note 2: A low capacitance (<12pF), 10X attenuation factor, high impedance (>10Mohms), and high bandwidth (>500MHz) passive probe is
recommended.
Note 3: Test circuit PCB traces need to be designed for a characteristic line impedance of 50 ohms.
www.ecliptek.com | Specification Subject to Change Without Notice | Revision A 05/11/2012 | Page 4 of 6
Ecliptek, LLC
5458 Louie Lane, Reno, NV 89511
1-800-ECLIPTEK or 714.433.1200
EMRE12F2H-173.3705M
Recommended Solder Reflow Methods
High Temperature Infrared/Convection
T
S
MAX to T
L
(Ramp-up Rate)
Preheat
- Temperature Minimum (T
S
MIN)
- Temperature Typical (T
S
TYP)
- Temperature Maximum (T
S
MAX)
- Time (t
S
MIN)
Ramp-up Rate (T
L
to T
P
)
Time Maintained Above:
- Temperature (T
L
)
- Time (t
L
)
Peak Temperature (T
P
)
Target Peak Temperature (T
P
Target)
Time within 5°C of actual peak (t
p
)
Ramp-down Rate
Time 25°C to Peak Temperature (t)
Moisture Sensitivity Level
3°C/Second Maximum
150°C
175°C
200°C
60 - 180 Seconds
3°C/Second Maximum
217°C
60 - 150 Seconds
260°C Maximum for 10 Seconds Maximum
250°C +0/-5°C
20 - 40 Seconds
6°C/Second Maximum
8 Minutes Maximum
Level 1
www.ecliptek.com | Specification Subject to Change Without Notice | Revision A 05/11/2012 | Page 5 of 6
Ecliptek, LLC
5458 Louie Lane, Reno, NV 89511
1-800-ECLIPTEK or 714.433.1200
