SMT Ball And Socket
Connector
Features
I
Designed for fast, consistent testing and
connection of SMT assemblies
I
Quick connect/ disconnect with
click
lock
feature
I
Wide range of movement allows
flexibility in applications.
I
Two heights of test points available
I
Supplied loose or on tape and reel for
production applications using pick and
place equipment
Specifications
Electrical and Mechanical
Recommended
Pad Size:
Contact resistance
(including socket):
Socket insulation
resistance:
Operating
temperature:
Current rating:
Max angular movement
before disconnection:
Retention force (typ):
Retention torque (typ):
1.4mm
(0.055”)
1.0mm
(.039")
0.4mm
(0.016”)
1.5mm
(0.059”)
2mm
(0.079”)
0.5mm
(0.020”)
2mm
(0.079”)
1.5mm
(0.059”)
0.5mm
(0.020”)
2 mm
2 mΩ (max)
10,000 MΩ
- 55 to +125 C
3A
±30
2 Kg.
200 gcm.
o
o
o
3.2mm
(0.126”)
Connecting Wire
1.3mm
(0.051”) Max
Dimensions
11.5mm (0.453”)
Ordering Information
Description
Socket, white
Test point, H = 2mm
Unit of Sale
Each
Each
Part Number
02-1033
02-1032
02-1049
02-1050
02-1080
Test point, H = 1.4mm Each
Test point, H = 1.4mm Reel, 3K pcs.
Test point, H = 2mm
Reel, 2K pcs.
Tape and Reel (02-105X only)
Reel sizes: 7" (2K & 3K test points)
13" (10K test points)
Tape:
4mm spacing, 8mm width
SMT Test Points
Stainless Steel
These test point are designed to facilitate
the connection of test probes to PCBs
which are primarily surface mount in
design. Supplied on tape and reel, these
test points are readily inserted with most
common pick and place equipment.
Note: Tops of test points are not plated.
Be sure to orient properly before soldering.
Ni Plating
SnCu
View A
0.063
0.031
0.009
0.045
Specifications
Electrical
Contact resistance: <50mΩ
Current rating:
2A
Operating
o
o
temperature:
- 55 to +125 C
Materials & Finishes
Material:
Finish:
Packaging:
Stainless Steel
(SUS 304)
SnCu
Parts on 4mm
pitch / 8mm tape
width. 2,000
* Quanties less than 2,000
pieces are supplied on tape
cut from reel.
0.009
89-1057
See View
A
0.079
0.049
0.018
0.057
0.002
0.063
0.126
0.079
0.009
89-1058
See View
A
0.001
89-1065
See View
A
Ordering Information
P/N
Lead-Free
89-1057
89-1058
89-1065
Description
0603 Test Point
0805 Test Points
1206 Test Points
Length
.063” (1.6 mm)
.126” (3.2 mm)
Width
.031” (0.8 mm)
.063” (1.6 mm)
Height
.045” (1.15 mm)
.079” (2.0 mm)
.079” (2.0 mm) .049” (1.25 mm) .057” (1.45 mm)
5
415 Howe Avenue, Suite LL160, Shelton, CT 06484-3168 U.S.A.
I
1-800-831-5383
Phone: (203) 922-1182
I
FAX: (203) 922 -8231
I
Web Site: http://www.e-markinc.com
