433-3230-900XL datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> 433-3230-900XL

433-3230-900XL: DescriptionLED Traffic Modules; CategoryLED optoelectronic/LED photoelectric; File Size119KB，1 Pages; ManufacturerDIALIGHT; Websitehttps://www.dialight.com

Download Datasheet Parametric Compare View All

433-3230-900XL Overview

LED Traffic Modules

433-3230-900XL Parametric

Parameter Name	Attribute value
Reach Compliance Code	compli
Other features	UL RECOGNIZED
color	YELLOW
Maximum forward current	0.52 A
Number of functions	1
Maximum operating temperature	74 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED DISPLAY CLUSTER
Base Number Matches	1

Preview

Download Datasheet

View All

features / Benefits

Robust High Flux LED Technology

LED Traffic Modules

for use with External Constant Current

DC Drive Applications

Ideal for Solar and Battery Application When Used With

LED Driver Provided by Others

Long Life

Standard 8” and 12” Modules

Fully Sealed Module

Incandescent Appearance

Abrasion Resistant Lens Coating

Easy to Install into Existing Signal Enclosure

speCifiCations

Constant current DC drive source required

(provided by others)

Quick connect terminals with spade / tab

adapters

Colored Wire - Positive, White Wire - Negative

Operating Temperature Range: -40°C to +74°C

Vibration resistant to Mil-Std-883, Test method

2007

Moisture Resistant per MIL-STD-810F, Method

506.4 for rain and blowing rain

Caution:

These Dialight LED traffic signal modules do not contain any internal LED Driver circuitry that would limit the current to the

LEDs. These LED modules

must be driven with a customer supplied constant current source.

Failure to drive these LED modules

from a constant current source or exceeding the drive current specification for the devices can result in catastrophic failure of the LEDs.

Since LED drive current is a function of the system design, LED product warranty is assumed by the system designer / supplier.

8” (200 mm) signal modules

with no internal driver CirCuit

Part Number

433-1110-000XL

433-3130-900XL

433-2120-000XL

433-2170-000XL

Color

Red

Yellow

Green

Lens Type

Tinted

Clear

Min Luminous

Intensity* (cd)

165

410

215

Dominant

Wavelength (nm)

625

590

500

Max Input

Drive Current

(mAmps)

375

520

600

12” (300 mm) signal modules

with no internal driver CirCuit

Part Number

433-1210-000XL

433-3230-900XL

433-2220-000XL

433-2270-000XL

Color

Red

Yellow

Green

Lens Type

Tinted

Clear

Min Luminous

Intensity* (cd)

365

910

475

Dominant

Wavelength (nm)

625

590

500

Max Input

Drive Current

(mAmps)

340

520

345

* Measured at peak intensity point, when driven at the above specified max input drive current.

Dialight reserves the right to make changes at any time in order to supply the best product possible.

The most current version of this document will always be available at:

www.dialight.com/Assets/Brochures_And_Catalogs/Illumination/MDTS433EC001.pdf

MDTS433EC001_A

www.dialight.com

433-3230-900XL Related Products

	433-3230-900XL	433-1110-000XL	433-1210-000XL	433-2120-000XL	433-2170-000XL	433-2220-000XL	433-2270-000XL	433-3130-900XL
Description	LED Traffic Modules	LED Traffic Modules	LED Traffic Modules	LED Traffic Modules	LED Traffic Modules	LED Traffic Modules	LED Traffic Modules	LED Traffic Modules
Reach Compliance Code	compli	compliant	compli	compli	compliant	compli	compliant	compli
Other features	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED
color	YELLOW	RED	RED	GREEN	GREEN	GREEN	GREEN	YELLOW
Maximum forward current	0.52 A	0.375 A	0.34 A	0.6 A	0.6 A	0.345 A	0.345 A	0.52 A
Number of functions	1	1	1	1	1	1	1	1
Maximum operating temperature	74 °C	74 °C	74 °C	74 °C	74 °C	74 °C	74 °C	74 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Optoelectronic device types	SINGLE COLOR LED DISPLAY CLUSTER	SINGLE COLOR LED DISPLAY CLUSTER	SINGLE COLOR LED DISPLAY CLUSTER	SINGLE COLOR LED DISPLAY CLUSTER	SINGLE COLOR LED DISPLAY CLUSTER	SINGLE COLOR LED DISPLAY CLUSTER	SINGLE COLOR LED DISPLAY CLUSTER	SINGLE COLOR LED DISPLAY CLUSTER
Base Number Matches	1	1	1	1	1	1	1	-
