DATA SHEET
NEC's WIDE BAND
UPD5710TK
SINGLE CONTROL CMOS SPDT SWITCH
FEATURES
•
SUPPLY VOLTAGE :
1.8 to 3.3 V (2.8 V TYP.)
SINGLE SWITCH CONTROL VOLTAGE:
V
cont (H)
= 1.8 to 3.3 V (2.8 V TYP.)
V
cont (L)
=
−0.2
to +0.2 V (0 V TYP.)
LOW INSERTION LOSS:
0.6 dB TYP. @ DC to 1.0 GHz
0.8 dB TYP. @ 1.0 to 2.0 GHz
0.95 dB TYP. @ 2.0 to 2.5 GHz
DESCRIPTION
NEC's UPD5710TK is a wide-band single control
CMOS MMIC SPDT (Single Pole Double Throw)
switch for mobile communications, instrumentation,
short range wireless, and general-purpose RF
switching applications.
This device can operate from DC to 2.5GHz with low
insertion loss and high isolation, and generally does
not require blocking capacitors on the RF lines.
The UPD5710TK is housed in a Pb-Free 6-pin
minimold (1511) package, suitable for high-density
surface mounting.
•
•
• HIGH ISOLATION:
32.5 dB TYP. @ DC to 1.0 GHz
25 dB TYP. @ 1.0 to 2.0 GHz
22.5 dB TYP. @ 2.0 to 2.5 GHz
• POWER HANDLING:
P
in (0.1 dB)
= +17.0 dBm TYP. @ 1.0GHz, V
DD
= 2.8 V
P
in (1 dB)
= +21.0 dBm TYP. @ 1.0 GHz, V
DD
= 2.8 V
• HIGH-DENSITY SURFACE MOUNT PACKAGE:
6-pin minimold package (1.5
×
1.1
×
0.55 mm)
• Pb-FREE
APPLICATIONS
•
•
•
•
MOBILE COMMUNICATIONS
SET TOP BOXES
SHORT RANGE WIRELESS
INSTRUMENTATION
ORDERING INFORMATION
PART NUMBER
μPD5710TK-E2-A
PACKAGE
6-pinlead-less minimold (1511)
MARKING
C3L
SUPPLYING FORM
•
Embossed tape 8 mm wide
•
Pin 1, 6 face the perforation side of the tape
•
Qty 5 kpcs/reel
Remark
To order evaluation samples, contact your nearby sales office.
Part number for sample order: UPD5710TK
California Eastern Laboratories
UPD5710TK
PIN CONNECTIONS AND INTERNAL BLOCK DIAGRAM
PIN NO.
1
2
3
4
5
6
PIN NAME
OUTPUT1
GND
OUTPUT2
V
cont
INPUT
V
DD
TRUTH TABLE
V
CONT
Low
High
INPUT−OUTPUT1
OFF
ON
INPUT−OUTPUT2
ON
OFF
ABSOLUTE MAXIMUM RATINGS
(T
A
=+25ºC, unless otherwise specified)
PARAMETER
Supply Voltage
Switch Control Voltage
Continuous Current
Input Power
Operating Ambient Temperature
Storage Temperature
SYMBOL
V
DD
V
cont
I
dc
P
in
T
A
T
stg
RATINGS
+4.6
+4.6
60
+27
−45
to +85
−65
to +150
UNIT
V
V
mA
dBm
°C
°C
RECOMMENDED OPERATING RANGE
(T
A
=+25ºC, unless otherwise specified)
PARAMETER
Supply Voltage
Switch Control Voltage (H)
Switch Control Voltage (L)
SYMBOL
V
DD
V
cont (H)
V
cont (L)
MIN.
+1.8
+1.8
−0.2
TYP.
+2.8
+2.8
0
MAX.
+3.3
+3.3
+0.2
UNIT
V
V
V
Notes 1.
|
V
cont(H)
−
V
cont(L)
|
≤
0.1 V
UPD5710TK
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, V
DD
= 2.8V, V
cont(H)
= 2.8 V , V
cont(L)
= 0 V, unless otherwise specified)
PARAMETER
Insertion Loss 1
Insertion Loss 2
Insertion Loss 3
Isolation 1
Isolation 2
Isolation 3
Input Return Loss
Output Return Loss
0.1 dB Loss Compression
Input Power
Note
1 dB Loss Compression
Input Power
Note
Intermodulation Intercept Point
Supply Current
Switch Control Current
Switch Control Speed
SYMBOL
L
ins1
L
ins2
L
ins3
ISL1
ISL2
ISL3
RL
in
RL
out
P
in (0.1 dB)
P
in (1 dB)
IIP
3
I
DD
I
cont
t
SW
TEST CONDITIONS
f = DC to 1.0 GHz
f = 1.0 to 2.0 GHz
f = 2.0 to 2.5 GHz
f = DC to 1.0 GHz
f = 1.0 to 2.0 GHz
f = 2.0 to 2.5 GHz
f = DC to 2.5 GHz
f = DC to 2.5 GHz
f = 1.0 GHz
f = 1.0 GHz
2 tone, 1.000/1.001GHz,
1 MHz spacing
No RF
No RF
MIN.
−
−
−
30
22
-
15
15
+13.5
−
−
−
-
−
TYP.
0.6
0.8
0.95
32.5
25
22.5
20
20
+17.0
+21.0
+33
0.01
0.01
30
MAX.
0.8
1.0
1.2
−
−
−
−
−
−
−
−
1.0
1.0
500
UNIT
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
dBm
μA
μA
ns
Notes .
P
in (0.1 dB)
or P
in (1 dB)
are the measured input power level when the insertion loss increases 0.1 dB more
or 1dB than that of linear range.
