B59060-A160-A10

Description
RESISTOR, TEMPERATURE DEPENDENT, PTC, 9ohm, CHASSIS MOUNT
CategoryPassive components    The resistor
File Size95KB，2 Pages
ManufacturerEPCOS (TDK)
Environmental Compliance
Download Datasheet Parametric Compare View All

B59060-A160-A10 Overview

RESISTOR, TEMPERATURE DEPENDENT, PTC, 9ohm, CHASSIS MOUNT

B59060-A160-A10 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerEPCOS (TDK)
package instruction,
Reach Compliance Codecompliant
JESD-609 codee4
Installation featuresCHASSIS MOUNT
Number of terminals2
Maximum operating temperature200 °C
Minimum operating temperature-40 °C
Package shapeDISK PACKAGE
method of packingTRAY
Rated (AC) voltage (URac)12 V
resistance9 Ω
Resistor typePTC THERMISTOR
surface mountNO
Terminal surfaceSilver (Ag)
Terminal shapeSPECIAL
Thermistor ApplicationsHEATING ELEMENT
Tolerance30%

Preview

Download Datasheet
Heating Elements and Thermostats
B59060
A 60
12 V
Applications
q
Heating element for small heating systems,
e. g. in automobiles
Features
q
Thermistor disk with silver metallization
on front surfaces
q
Suitable for clamp-contacting and
glue-bonding
q
Curvature < 0,2 mm
Options
Other dimensions and electrical parameters
available upon request
Termination
Dimensions (mm)
Max. operating voltage
Rated voltage
Breakdown voltage
Operating temperature range (V = 0)
(V =
V
N
)
Resistance tolerance
V
max
V
N
V
D
T
op
T
op
∆
R
30
12
> 36
– 40/+ 200
– 25/+ 60
±
30 %
1)
V
V
V
°C
°C
Type
T
Ref
°C
A 60
A 60
A 60
A 60
A 60
A 60
A 60
A 60
4)
A 60
0
40
60
80
120
160
180
220
280
R
min
(V =
V
N
)
Ω
20
2)
4
2)
5
4
4
3
3
2
3
T
surf 3)
(V =
V
N
)
°C
40
70
80
95
130
165
185
210
265
R
N
(V
Meas
≤
1,5 V)
Ω
≥
320
9
9
9
9
9
9
9
18
Ordering code
B59060-A-A10
B59060-A40-A10
B59060-A60-A10
B59060-A80-A10
B59060-A120-A10
B59060-A160-A10
B59060-A180-A10
B59060-A220-A10
B59060-A280-A10
1)
2)
3)
4)
Tolerance not valid for B59060-A-A10
Valid for
T
A
< 25
°C
Measured peak-to-peak
UL approval
164
Siemens Matsushita Components
