MILLIMETER-WAVE AMPLIFIERS
Advanced Control Components manufactures a wide
variety of high-performance millimeter-wave amplifiers.
The tables below list a small portion of the units we have
designed. Most parameters such as bandwidth, gain,
noise figure, compression point etc. can be tailored to your
requirements.
Contact the factory to discuss any
modifications or additions of special functions such as gain
control, power monitoring, temperature compensation, etc.
All models are available with hermetic seal and high-rel
screening for mil and spaced-based applications.
LOW NOISE AMPLIFIERS
Part
Number
AMPA143G1
AMPA169G3
AMPA162G2
AMPA248
AMPA149G1
Frequency
Range
(GHz)
24.25 - 25.25
24.25 - 25.25
27.5 - 29.5
27 - 31
31.0 - 31.3
Gain
(dB min)
24.5
27
26.5
30
23.5
Gain
Flatness
(+/-dB max)
1.5
1.5
1.0
1.0
Noise
Figure
(dB max)
4.0
4.0
4.0
7.0
4.0
1dB
Compression
(dBm min)
8
8
10
22
20
IP3
(+dBm typ)
17
17
18
30
28
Supply
Voltage
(VDC)
12
10
15
15
12
Current
(mA max)
250
250
170
600
650
Outline
Drawing
C-183
C-210
C-205
C-285
C-192
POWER AMPLIFIERS
Part
Number
AMPA133G1
AMPA133G2
AMPA151G1
AMPA205G3
AMPA148G2
AMPA147G1
AMPA171G1
AMPA170G2
AMPA167G1
AMPA170G1
Frequency
Range
(GHz)
24.25 - 25.25
24.258 - 25.25
24.5 - 25.25
24.5 - 26.5
28.1 - 28.45
27.5 - 28.5
27.5 - 28.5
28.35 - 29.25
29.1 - 29.3
29.0 - 29.35
Gain
(dB min)
50
52.5
24.5
50
57.5
49
52
52
58
52
Gain
Flatness
(+/-dB max)
1.5
1.5
1.5
1.0
1.5
2.5
1.0
1.0
1.0
1.0
Noise
Figure
(dB max)
8
8
8
5
8
8
8
8
10
8
1dB
Compression
(dBm min)
25
26
30
24
24
30
30
30
36
30
IP3
(+dBm typ)
33
33
38
37
32
38
38
38
42
38
Supply
Voltage
(VDC)
12
10
10
24
8
10
10
10
15
10
Current
(mA max)
2000
2000
2500
2000
1500
5000
3500
3500
3500
3500
Outline
Drawing
C-183
C-183
C-195
C-207
C-193
C-191
C-207
C-207
C-208
C-207
Notes:
•
•
•
•
•
•
•
All specifications guaranteed at +25°C.
Operating temperature range: -50°C to +70°C. Extended operating temperature range available.
VSWR is specified at 2.0:1 maximum input and output at 50Ω. Typical performance is 1.7:1.
All models can be optimized for different frequency ranges.
Custom packaging is available for all models.
Standard package finish: Gold Plate per MIL-G-45204.
RF connectors per MIL-PRF-39012 (K female standard)
tel: 732-460-0212 fax: 732-460-0214
sales@advanced-control.com
www.advanced-control.com
611 Industrial Way West, Eatontown, NJ 07724
ENVIRONMENTAL SPECIFICATIONS:
MIL-E-5400, MIL-STD-202, MIL-E-16400
Operating Temp: -50°C to +70°C
Storage Temp: -65°C to +125°C
Humidity: MIL-STD-202F, M103, Cond B
Shock: MIL-STD-202F, M213, Cond B
Altitude: MIL-STD-202F, M105, Cond B
Vibration
: MIL-STD-202F, M204, Cond B
Thermal Shock: MIL-STD-202F, M107, Cond A
Temperature Cycle: MIL-STD-202F, M105C, Cond D
SCREENING :
Standard Screening:
Internal Visual per MIL-STD-883, Method 2017
Temperature Cycle: -65°C to +100°C, 10 cycles
Optional High-Rel Screening (Ref MIL-PRF-38534):
Internal Visual per MIL-STD-883, Method 2017
Stabilization Bake per MIL-STD-883, Method 1008
Temperature Cycle per MIL-STD-883, Method 1010
Constant Acceleration per MIL-STD-883, Method 2001
Burn-in per MIL-STD-883, Method 1015
Leak Test per MIL-STD-883, Method 1014
External Visual per MIL-STD-883, Method 2009
Refer to Standard Millimeter Amplifier Outline Drawing specification for mechanical details
OPTIONS:
•
Custom frequency ranges available to 40GHz
•
Alternate standard and custom packaging
•
Available as open cards or drop-in modules
•
Hermetic seal
•
Integrated power supplies
•
Multiple outputs
•
Interstage access points
•
Hi-rel screening
•
•
•
•
•
•
•
•
Supply voltage options
Voltage-controlled gain
Temperature compensation
Input and output limiting
Integrated filters
Unit-to-unit gain and phase matching
Detected outputs
Power monitoring
* Contact the factory for price and delivery or to discuss options and custom requirements
Advanced Control Components is your source for custom amplifiers and amplifier assemblies. With complete design
and test capability to 40GHz, we have the resources to help develop and realize a new design, build to an existing
specification or replace an obsolete component. From commercial to space qualified applications, we can help.
In addition to high performance amplifier design capability, Advanced Control Components produces custom
amplifier-based multi-function assemblies to 40GHz. With our extensive expertise, we can integrate a wide variety of
components and functions such as mixers, limiters, switches, attenuators, combiners/dividers, filters, detectors, etc.
Additional capabilities include microprocessor control and monitoring, RF signal monitoring, and power supply
conditioning. Contact the factory to discuss your design and application.
MM-0305
611 Industrial Way West, Eatontown, NJ 07724
tel: 732-460-0212 fax: 732-460-0214
sales@advanced-control.com
www.advanced-control.com
