Pacific Silicon Sensor Series 2 Data Sheet
Part Description PC1-2-CH
Order # 41-010
1.56 SQ
ACTIVE AREA: 1.0 mm
2
Ø1.13
CATHODE
BONDING RING
ALUMINUM
0.13 WIDE
FIELD METAL
NO CONNECTION
0.38
±.02
BACKSIDE ANODE
GOLD ALLOY
R
o
H
FEATURES
•
•
•
•
∅
1.13 mm active area
Long term stability
High sensitivity
UV/ Blue enhanced
DESCRIPTION
1.0 mm UV Silicon Photodiode with N on P construction.
2
APPLICATIONS
•
•
•
•
UV exposure meters
Pollution monitoring
Fluorescent analyzers
Medical instrumentation
S
C
PLI
A
NT
OM
ABSOLUTE MAXIMUM RATING
SYMBOL PARAMETER
MIN
T
STG
T
OP
V
R(OP)
I
(PEAK)
Storage Temp
Operating Temp
Reverse Operating
Voltage
Peak DC Current
-55
-40
-
-
SPECTRAL RESPONSE
MAX
+125
+100
50
10
UNITS
°C
°C
RESPONSIVITY (A/W)
0.45
0.40
0.35
0.30
0.25
0.20
0.15
0.10
0.05
0.00
200
300
400
500
600
700
800
900
1000 1100
V
mA
SCHEMATIC
TOP PAD
CATHODE
BACKSIDE
ANODE
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS @ 22° C
SYMBOL
CHARACTERISTIC
TEST CONDITIONS
R
SH
I
D
C
Shunt Resistance
Dark Current
Capacitance
Responsivity
NEP
V
BR
t
r
Noise Equivalent Power
Breakdown Voltage
Rise Time
V
R
= ±10 mV
V
R
= 5 V
V
R
= 0 V
V
R
= 5 V
V
R
= 0 V;
λ
= 340 nm
V
R
= 0 V;
λ
= 850 nm
V
R
= 0 V;
λ
= 850 nm; R
L
= 50
Ω
I
R
= 10 µA
V
R
= 5 V;
λ
= 410 nm; R
L
= 50
Ω
MIN
500
---
---
---
---
---
---
30
---
TYP
2000
0.2
60
30
0.17
0.42
-15
8.0 X 10
50
0.1
MAX
---
---
---
---
---
---
---
---
---
UNITS
MΩ
nA
pF
A/W
W/Hz
V
µs
1/2
These devices are sensitive to electrostatic discharge. Please use ESD precautions when handling.
Disclaimer: Due to our policy of continued development, specifications are subject to change without notice.
USA:
Pacific Silicon Sensor, Inc.
5700 Corsa Avenue, #105
Westlake Village, CA 91362 USA
Phone (818) 706-3400
Fax (818) 889-7053
Email:
sales@pacific-sensor.com
www.pacific-sensor.com
International sales:
Silicon Sensor GmbH
Wilhelminenhofstrasse 76-77
D-12459 Berlin, Germany
Phone +49 (0)30-63 99 23 10
Fax +49 (0)30-63 99 23 33
Email:
sales@silicon-sensor.de
www.silicon-sensor.de
Proud Members of the Silicon Sensor AG Group of companies
2/23/2009
Pacific Silicon Sensor Series 6 Data Sheet
Part Description PC1-6-CH
Order # 41-119
1.56 SQ
ACTIVE AREA: 1.0 mm
2
Ø1.13
ANODE
BONDING RING
ALUMINUM
0.13 WIDE
FIELD METAL
NO CONNECTION
±.02
0.38
BACKSIDE CATHODE
GOLD ALLOY
H
FEATURES
•
•
•
•
∅
1.13 mm active area
Low dark current
Long term stability
High shunt resistance
DESCRIPTION
1.0 mm Low Dark Current PIN Photodiode.
2
APPLICATIONS
•
•
•
•
Precision photometry
Bar code readers
Medical equipment
Pulsed light sensor
S
C
PLI
A
NT
OM
ABSOLUTE MAXIMUM RATING
SYMBOL PARAMETER
MIN
T
STG
T
OP
V
R(OP)
I
(PEAK)
Storage Temp
Operating Temp
Reverse Operating
Voltage
Peak DC Current
-55
-40
-
-
SPECTRAL RESPONSE
MAX
+125
+100
50
10
UNITS
°C
°C
V
RESPONSIVITY (A/W)
0.70
0.60
0.50
0.40
0.30
0.20
0.10
0.00
400
mA
SCHEMATIC
BACKSIDE
CATHODE
TOP PAD
ANODE
500
600
700
800
900
1000
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS @ 22° C
SYMBOL
CHARACTERISTIC
TEST CONDITIONS
R
SH
I
D
C
Shunt Resistance
Dark Current
Capacitance
Responsivity
NEP
V
BR
t
r
Noise Equivalent Power
Breakdown Voltage
Rise Time
V
R
= ±10 mV
V
R
= 10 V
V
R
= 0 V;
V
R
= 10 V;
V
R
= 0 V;
λ
= 633 nm
V
R
= 0 V;
λ
= 900 nm
V
R
= 10 V;
λ
= 850 nm; R
L
= 50
Ω
I
R
= 10 µA
V
R
= 10 V;
λ
= 850 nm; R
L
= 50
Ω
V
R
= 80 V;
λ
= 850 nm; R
L
= 50
Ω
MIN
1000
---
---
---
---
---
---
100
---
---
TYP
2000
0.05
15
3.0
0.40
0.64
6.5 X 10
---
10
5
-15
MAX
---
---
---
---
---
---
---
---
---
---
R
o
1100
UNITS
MΩ
nA
pF
A/W
W/Hz
V
ns
1/2
Disclaimer: Due to our policy of continued development, specifications are subject to change without notice.
USA:
Pacific Silicon Sensor, Inc.
5700 Corsa Avenue, #105
Westlake Village, CA 91362 USA
Phone (818) 706-3400
Fax (818) 889-7053
Email:
sales@pacific-sensor.com
www.pacific-sensor.com
2/23/2009
International sales:
Silicon Sensor GmbH
Wilhelminenhofstrasse 76-77
D-12459 Berlin, Germany
Phone +49 (0)30-63 99 23 10
Fax +49 (0)30-63 99 23 33
Email:
sales@silicon-sensor.de
www.silicon-sensor.de
Proud Members of the Silicon Sensor AG Group of companies
Pacific Silicon Sensor Ultra Blue Series Data Sheet
Part Description PC1-6B-CH
Order # 41-153
1.56 SQ
ACTIVE AREA: 1.0 mm
2
Ø1.13
ANODE
BONDING RING
ALUMINUM
0.13 WIDE
FIELD METAL
NO CONNECTION
±.02
0.38
BACKSIDE CATHODE
GOLD ALLOY
H
FEATURES
•
•
•
•
∅1.13
mm active area
Low dark current
Long term stability
Ultra blue enhanced
DESCRIPTION
1.00 mm Low Dark Current Photodiode with P on N
construction.
2
APPLICATIONS
•
•
•
•
Precision photometry
Analytical instruments
Medical equipment
Pulsed light sensor
S
C
PLI
A
NT
OM
ABSOLUTE MAXIMUM RATING
SYMBOL PARAMETER
MIN
T
STG
T
OP
V
R(OP)
I
(PEAK)
Storage Temp
Operating Temp
Reverse Operating
Voltage
Peak DC Current
-55
-40
-
-
SPECTRAL RESPONSE
MAX
+125
+100
50
10
UNITS
°C
°C
V
mA
RESPONSIVITY (A/W)
0.70
0.60
0.50
0.40
0.30
0.20
0.10
0.00
SCHEMATIC
BACKSIDE
CATHODE
TOP PAD
ANODE
350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS @ 22° C
SYMBOL
CHARACTERISTIC
TEST CONDITIONS
R
SH
I
D
C
Shunt Resistance
Dark Current
Capacitance
Responsivity
NEP
V
BR
t
r
Noise Equivalent Power
Breakdown Voltage
Rise Time
V
R
= ±10 mV
V
R
= 5 V
V
R
= 0 V;
V
R
= 5 V;
V
R
= 0 V;
λ
= 410 nm
V
R
= 0 V;
λ
= 550 nm
V
R
= 5 V;
λ
= 410 nm; R
L
= 50
Ω
I
R
= 10 µA
V
R
= 5 V;
λ
= 410 nm; R
L
= 50
Ω
MIN
700
---
---
---
---
---
---
50
---
TYP
1000
0.05
30
18
0.22
0.37
1.8 X 10
---
10
-14
MAX
---
---
---
---
---
---
---
---
---
R
o
UNITS
MΩ
nA
pF
A/W
W/Hz
V
ns
1/2
Disclaimer: Due to our policy of continued development, specifications are subject to change without notice.
USA:
Pacific Silicon Sensor, Inc.
5700 Corsa Avenue, #105
Westlake Village, CA 91362 USA
Phone (818) 706-3400
Fax (818) 889-7053
Email:
sales@pacific-sensor.com
www.pacific-sensor.com
2/23/2009
International sales:
Silicon Sensor GmbH
Wilhelminenhofstrasse 76-77
D-12459 Berlin, Germany
Phone +49 (0)30-63 99 23 10
Fax +49 (0)30-63 99 23 33
Email:
sales@silicon-sensor.de
www.silicon-sensor.de
Proud Members of the Silicon Sensor AG Group of companies
Pacific Silicon Sensor Series 7 Data Sheet
Part Description PC1-7-CH
Order # 41-042
1.56 SQ
ACTIVE AREA: 1.0 mm
2
Ø1.13
ANODE
BONDING RING
ALUMINUM
0.13 WIDE
FIELD METAL
NO CONNECTION
±.02
0.38
BACKSIDE CATHODE
GOLD ALLOY
R
o
H
FEATURES
•
•
•
•
∅
1.13 mm active area
Low capacitance
Long term stability
High NIR sensitivity
DESCRIPTION
1.0 mm Low Capacitance PIN Photodiode.
2
APPLICATIONS
•
•
•
•
Laser detection
Instrumentation
Optical remote control
Pulsed light sensor
S
C
PLI
A
NT
OM
ABSOLUTE MAXIMUM RATING
SYMBOL PARAMETER
MIN
T
STG
T
OP
V
R(OP)
I
(PEAK)
Storage Temp
Operating Temp
Reverse Operating
Voltage
Peak DC Current
-55
-40
-
-
SPECTRAL RESPONSE
MAX
+125
+100
50
10
UNITS
°C
°C
V
mA
RESPONSIVITY (A/W)
0.70
0.60
0.50
0.40
0.30
0.20
0.10
0.00
300
SCHEMATIC
BACKSIDE
CATHODE
400
500
600
700
800
900
1000
1100
TOP PAD
ANODE
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS @ 22° C
SYMBOL
CHARACTERISTIC
TEST CONDITIONS
I
D
C
Dark Current
Capacitance
Responsivity
NEP
V
BR
t
r
Noise Equivalent Power
Breakdown Voltage
Rise Time
V
R
= 12 V
V
R
= 12 V
V
R
= 0 V;
λ
= 950 nm
V
R
= 0 V;
λ
= 1064 nm
V
R
= 12 V;
λ
= 850 nm; R
L
= 50
Ω
I
R
= 10 µA
V
R
= 12 V;
λ
= 850 nm; R
L
= 50
Ω
MIN
---
---
---
---
---
30
---
TYP
0.5
2.0
0.65
0.20
1.0 X 10
---
30
-14
MAX
---
---
---
---
---
---
---
UNITS
nA
pF
A/W
W/Hz
V
ns
1/2
Disclaimer: Due to our policy of continued development, specifications are subject to change without notice.
USA:
Pacific Silicon Sensor, Inc.
5700 Corsa Avenue, #105
Westlake Village, CA 91362 USA
Phone (818) 706-3400
Fax (818) 889-7053
Email:
sales@pacific-sensor.com
www.pacific-sensor.com
2/23/2009
International sales:
Silicon Sensor GmbH
Wilhelminenhofstrasse 76-77
D-12459 Berlin, Germany
Phone +49 (0)30-63 99 23 10
Fax +49 (0)30-63 99 23 33
Email:
sales@silicon-sensor.de
www.silicon-sensor.de
Proud Members of the Silicon Sensor AG Group of companies
