Silicon RF Power Semiconductors

ELECTROSTATIC SENSITIVE DEVICE

OBSERVE HANDLING PRECAUTIONS

RA35H1516M

BLOCK DIAGRAM

RoHS Compliance ,

154-162MHz 40W 12.5V, 2 Stage Amp. For MOBILE RADIO

DESCRIPTION

The RA35H1516M is a 40-watt RF MOSFET Amplifier

Module for 12.5-volt mobile radios that operate in the 154- to

162-MHz range.

The battery can be connected directly to the drain of the

enhancement-mode MOSFET transistors. Without the gate

voltage (V

=0V), only a small leakage current flows into the

drain and the RF input signal attenuates up to 60 dB. The output

power and drain current increase as the gate voltage increases.

With a gate voltage around 4V (minimum), output power and

drain current increases substantially. The nominal output power

becomes available at 4.5V (typical) and 5V (maximum). At

=5V, the typical gate current is 1 mA.

This module is designed for non-linear FM modulation, but may

also be used for linear modulation by setting the drain quiescent

current with the gate voltage and controlling the output power

with the input power.

FEATURES

• Enhancement-Mode MOSFET Transistors

≅0

@ V

=12.5V, V

=0V)

• P

out

>40W,

>50% @ V

=12.5V, V

=5V, P

=50mW

• Low-Power Control Current I

=1mA (typ) at V

=5V

• Module Size: 66 x 21 x 9.88 mm

• Linear operation is possible by setting the quiescent drain

current with the gate voltage and controlling the output power

with the input power

RF Input (P

)

Gate Voltage (V

), Power Control

Drain Voltage (V

), Battery

RF Output (P

out

)

RF Ground (Case)

PACKAGE CODE: H2S

RoHS COMPLIANCE

• RA35H1516M-101 is a RoHS compliant products.

• RoHS compliance is indicate by the letter “G” after the Lot Marking.

• This product include the lead in the Glass of electronic parts and the

lead in electronic Ceramic parts.

How ever,it is applicable to the following exceptions of RoHS Directions.

1.Lead in the Glass of a cathode-ray tube, electronic parts, and

fluorescent tubes.

2.Lead in electronic Ceramic parts.

ORDERING INFORMATION:

ORDER NUMBER

RA35H1516M-101

SUPPLY FORM

Antistatic tray,

10 modules/tray

RA35H1516M

25 Jun 2010

1/8
