KBP208 Overview

BRIDGE RECTIFIER DIODE

KBP208 Parametric

Parameter Name	Attribute value
state	ACTIVE
Diode type	bridge rectifier diode

Preview

Download Datasheet

View All

Suntan Su

®

KBP2005 THRU KBP210

Single Phase 2.0 AMPS. Glass Passivated Bridge Rectifiers

Voltage Range 50 to 1000 Volts

Current 2.0 Amperes

FEATU R E S

◆Ideal

for printed circuit board

◆Reliable

low cost construction technique

results in inexpensive product

◆High

temperature soldering guaranteed:

250℃

/ 10 seconds / 0.375” ( 9.5mm )

lead length at 5 lbs., ( 2.3 kg ) tension

◆UL

Recognized File number: E347215

MECHANICAL DATA

◆Case:

Molded plastic

◆Lead:

solder plated

◆Polarity:

As marked

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load. For capacitive load, derate current by 20%

Type Number

Maximum Repetitive Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC blocking Voltage

Maximum Average Forward Rectified Current

Peak Forward Surge Current, 8.3 ms Single

Half Sine-wave Superimposed on Rated

Load (JEDEC method )

Maximum Instantaneous Forward Voltage @ 3.14A

Maximum DC Reverse Current @ T

A

=25℃

I

R

rated DC blocking voltage per leg T

A

= 125℃

R

θJA

Typical Thermal Resistance (Note)

R

θJL

Operating Temperature Range

Storage Temperature Range

T

J

T

STG

V

F

@T

A

= 50℃

V

RRM

V

RMS

V

DC

I

(AV)

KBP

2005

KBP

201

KBP

202

KBP

204

KBP

206

KBP

208

KBP

210

UNITS

50

35

50

100

70

100

200

140

200

400

280

400

2.0

600

420

600

800

560

800

1000

700

1000

V

A

I

FSM

60

A

1.2

10

500

25

8.0

-55 to +150

V

μA

℃/W

℃

NOTE：

Thermal Resistance from Junction to Ambient and from Junction to Lead Mounted on P.C.B. with 0.47×0.47”(12×12mm) Copper Pads

1
