SRC1203EF
NPN Silicon Transistor
Descriptions
•
Switching application
•
Interface circuit and driver circuit application
PIN Connection
OUT
OUT
IN
Features
•
With built-in bias resistors
•
Simplify circuit design
•
Reduce a quantity of parts and
manufacturing process
•
High packing density
COMMON
IN
R
1
R
2
R
1
22KΩ
R
2
22KΩ
COMMON
Ordering Information
Type NO.
SRC1203EF
Marking
R3
□
① ②
①Device
Code
②Year&Week
Code
Package Code
SOT-523F
Absolute Maximum Ratings
Characteristic
Output voltage
Input voltage
Output current
Power dissipation
Junction temperature
Storage temperature range
(Ta=25°C)
Symbol
V
O
V
I
I
O
P
D
T
J
T
stg
Rating
50
40,-10
100
150
150
-55 ~ 150
Unit
V
V
mA
mW
°C
°C
Electrical Characteristics
Characteristic
Output cut-off current
DC current gain
Output voltage
Input voltage (ON)
Input voltage (OFF)
Transition frequency
Input current
Input resistor (Input to base)
Input resistor (Base to common)
(Ta=25°C)
Symbol
I
O(OFF)
G
I
V
O(ON)
V
I(ON)
V
I(OFF)
f
T
*
I
I
R
1
R
2
Test Condition
V
O
=50V, V
I
=0
V
O
=5V, I
O
=10mA
I
O
=10mA, I
I
=0.5mA
V
O
=0.2V, I
O
=5mA
V
O
=5V, I
O
=0.1mA
V
O
=10V, I
O
=5mA, f=1MHz
V
I
=5V, I
O
=0
-
-
Min. Typ. Max.
-
70
-
-
1.0
-
-
15.4
15.4
-
120
0.1
2.1
1.2
200
-
22
22
500
-
0.3
3.0
-
-
0.36
28.6
28.6
Unit
nA
-
V
V
V
MHz
mA
KΩ
KΩ
* : Characteristic of transistor only
KSD-R5E006-000
1
SRC1203EF
