200W Single Output Switching Power Supply
Features :
SE-200
series
AC input range selectable by switch
Protections: Short circuit / Overload / Over voltage/
Over temperature
Cooling by free air convection
Withstand 300vac surge input for 5 second
Built-in constant current limiting circuit
100% full load burn-in test
LED indicator for power on
Fixed switching frequency at 90KHz
Low cost,high reliability
2 years warranty
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
VOLTAGE ADJ. RANGE
VOLTAGE TOLERANCE
Note.3
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME
VOLTAGE RANGE
Note.4
FREQUENCY RANGE
INPUT
EFFICIENCY (Typ.)
AC CURRENT
INRUSH CURRENT (max.)
LEAKAGE CURRENT
OVER LOAD
PROTECTION OVER VOLTAGE
OVER TEMPERATURE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY
SAFETY STANDARDS
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
MTBF
OTHERS
NOTE
SE-200-3.3
3.3V
40A
0 ~ 40A
132W
2.97 ~ 3.7V
2.0%
0.5%
1.5%
20ms/230VAC
47 ~ 63Hz
75%
4.5A/115VAC
40A/115VAC
SE-200-5
5V
40A
0 ~ 40A
200W
150mVp-p
4.5 ~ 5.6V
2.0%
0.5%
1.0%
SE-200-7.5
7.5V
27A
0 ~ 27A
202.5W
150mVp-p
6 ~ 9V
2.0%
0.5%
1.0%
SE-200-12
12V
17A
0 ~ 17A
204W
150mVp-p
10 ~ 13.5V
1.0%
0.5%
0.5%
SE-200-15
15V
14A
0 ~ 14A
210W
150mVp-p
13.5 ~ 18V
1.0%
0.5%
0.5%
SE-200-24
24V
8.8A
0 ~ 8.8A
211.2W
150mVp-p
20 ~ 26.4V
1.0%
0.5%
0.5%
SE-200-27
27V
7.8A
0 ~ 7.8A
210.6W
200mVp-p
26 ~ 32V
1.0%
0.5%
0.5%
SE-200-36
36V
5.9A
0 ~ 5.9A
212.4W
240mVp-p
32 ~ 40V
1.0%
0.5%
0.5%
SE-200-48
48V
4.4A
0 ~ 4.4A
211.2W
240mVp-p
41 ~ 56V
1.0%
0.5%
0.5%
RIPPLE & NOISE (max.)
Note.2
150mVp-p
1000ms, 50ms/230VAC
1000ms,50ms/115VAC at full load
254 ~ 370VDC
85%
85%
87%
88%
89%
89%
16ms/115VAC at full load
90 ~ 132VAC / 180 ~ 264VAC by switch
79%
82%
2.5A/230VAC
55A/230VAC
<3.5mA / 240VAC
105 ~ 150% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
3.8 ~ 4.9V
5.75 ~ 7.0V 9.4 ~ 10.9V 13.8 ~ 16.2V 18 ~ 21V
27.6 ~ 32.4V 33.7 ~ 39.2V 41.4 ~ 46.8V 57.6 ~ 67.2V
Protection type :Shut down O/P voltage, re-power on to recover
95
5 (3.3V);100
5 (5V); 90
5 (7.5V);85
5 (12~24V);80
5 (27~36V);75
Protection type : Shut down O/P voltage, recovers automatically after temperature goes down
-20 ~ +50
(Refer to output load derating curve)
20 ~ 90% RH non-condensing
-20 ~ +85 , 10 ~ 95% RH
0.03%/ (0 ~ 50
10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes
UL60950-1 approved
I/P-O/P:3KVAC
I/P-FG:1.5KVAC
O/P-FG:0.5KVAC
/ 70% RH
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC / 25
271.9K hrs min. MIL-HDBK-217F (25 )
215*115*50mm (L*W*H)
0.93Kg; 12pcs/12Kg/0.92CUFT
5 (48V) (TSW1) Detect on case
DIMENSION
PACKING
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Please connect positive pole of input voltage with mark N of terminal block, connect negative pole of input voltage
with mark L of terminal block, using DC voltage for input voltage.
File Name:SE-200-SPEC 2012-02-28
