NSD15-D_10: Description15W DC-DC Regulated Dual Output; File Size229KB，2 Pages; ManufacturerMEAN WELL; Websitehttp://www.meanwell.com

Download Datasheet View All

NSD15-D_10 Overview

15W DC-DC Regulated Dual Output

Preview

Download Datasheet

View All

15W DC-DC Regulated Dual Output

Features :

Wide 4:1 DC input range

NSD15-D

Protections: Short circuit / Overload / Over voltage

1500VDC I/O isolation

Built-in EMI filter

Cooling by free air convection

Output voltage trimming function

Built-in remote ON-OFF control

100% full load burn-in test

Lost cost

High reliability

2 years warranty

series

SPECIFICATION

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

OUTPUT

CAPACITIVE LOAD (max.)

VOLTAGE TOLERANCE

Note.3

LINE REGULATION

LOAD REGULATION

TRIM OUTPUT (Typ.)

RATED DC INPUT

VOLTAGE RANGE

EFFICIENCY (Typ.)

NSD15-12D5

1.5A

15W

1000uF

3.0%

2.0%

5.0%

12VDC

Note.6

9.4 ~ 36VDC

76%

1.8A/12VDC

20mA

2.0%

1.0%

5.0%

2.0%

1.0%

3.0%

2.0%

5.0%

48VDC

18 ~ 72VDC

80%

0.4A/48VDC

2.0%

1.0%

5.0%

2.0%

1.0%

3.0%

-5V

1.5A

NSD15-12D12

12V

0.62A

-12V

0.62A

NSD15-12D15

15V

0.5A

-15V

0.5A

NSD15-48D5

1.5A

-5V

1.5A

NSD15-48D12

12V

0.62A

-12V

0.62A

NSD15-48D15

15V

0.5A

-15V

0.5A

0.07 ~ 1.5A 0.07 ~ 1.5A 0.03 ~ 0.62A 0.03 ~ 0.62A 0.02 ~ 0.5A 0.02 ~ 0.5A 0.07 ~ 1.5A 0.07 ~ 1.5A 0.03 ~ 0.62A 0.03 ~ 0.62A 0.02 ~ 0.5A 0.02 ~ 0.5A

RIPPLE & NOISE (max.)

Note.2

100mVp-p(25% ~ 100% load)

1.0% at 10% ~ 100% load

INPUT

80%

84%

DC CURRENT

SHUTDOWN IDLE CURRENT

OVERLOAD

PROTECTION

Above 105% rated output power

Protection type : Over power limiting, recovers automatically after fault condition is removed

-7.25 ~ -9V 13.8 ~ 18V -13.8 ~ -18V 17.3 ~ 22.5V -17.3 ~ -22.5V

FUNCTION

OVER VOLTAGE(CLAMP)

7.25 ~ 9V -7.25 ~ -9V 13.8 ~ 18V -13.8 ~ -18V 17.3 ~ 22.5V -17.3 ~ -22.5V 7.25 ~ 9V

SHORT CIRCUIT

Note.4

Recovers automatically after fault condition is removed

Logic "1" or open circuit : ON

Logic "0" or short to PIN2 : OFF

ON/OFF CONTROL

-25 ~ +70

WORKING TEMP.

WORKING HUMIDITY

0% ~ 95% RH max.

-40 ~ +85

, 0 ~ 95% RH

0.03%/ (0~50

UL60950-1 approved, Design refer to TUV EN60950-1

I/P-O/P:1.5KVDC

I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH

Compliance to EN55022 (CISPR22) Class B

ENVIRONMENT STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

SAFETY STANDARDS

SAFETY & ISOLATION VOLTAGE

ISOLATION RESISTANCE

EMC

(Note 5)

EMI CONDUCTION & RADIATION

EMS IMMUNITY

MTBF

OTHERS

DIMENSION

PACKING

NOTE

Compliance to EN61000-4-2,3,4,6,8; EN55024, light industry level, criteria A

1673.1K hrs min. MIL-HDBK-217F (25 )

50.8*38.1*9.82mm (2"*1.5"*0.387") (L*W*H)

0.03Kg; 180pcs/6.4Kg/0.97CUFT

1. All parameters NOT specially mentioned are measured at 12, 48VDC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. Short circuit no more than 60 seconds.

5. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

6. Derating to 80% load is needed for NSD15-48D series at 18Vdc input voltage. Full output wattage can be acquired when the input voltage is higher than 20Vdc.

7. EMC filter suggestion:

80uH

Vin

680uF

PSU

File Name:NSD15-D-SPEC 2010-10-18
