MAX7313_11 Overview

16-Port I/O Expander with LED Intensity Control, Interrupt, and Hot-Insertion Protection

19-3059; Rev 5; 6/11
16-Port I/O Expander with LED Intensity
Control, Interrupt, and Hot-Insertion Protection
General Description
The MAX7313 I
2
C-compatible serial interfaced periph-
eral provides microprocessors with 16 I/O ports. Each
I/O port can be individually configured as either an
open-drain current-sinking output rated at 50mA and
5.5V, or a logic input with transition detection. A 17th
port can be used for transition detection interrupt, or as
a general-purpose output. The outputs are capable of
driving LEDs, or providing logic outputs with external
resistive pullup up to 5.5V.
PWM current drive is integrated with 8 bits of control.
Four bits are global control and apply to all LED outputs
to provide coarse adjustment of current from fully off to
fully on with 14 intensity steps. Each output then has
individual 4-bit control, which further divides the global-
ly set current into 16 more steps. Alternatively, the cur-
rent control can be configured as a single 8-bit control
that sets all outputs at once.
The MAX7313 is pin and software compatible with the
MAX7311, PCA9535, and PCA9555.
Each output has independent blink timing with two blink
phases. All LEDs can be individually set to be on or off
during either blink phase, or to ignore the blink control.
The blink period is controlled by a register.
The MAX7313 supports hot insertion. All port pins, the
INT
output, SDA, SCL, and the slave-address inputs
ADO-2 remain high impedance in power-down (V+ =0V)
with up to 6V asserted upon them.
The MAX7313 is controlled through the 2-wire
I
2
C/SMBus serial interface, and can be configured to
any one of 64 I
2
C addresses.
o
2V to 3.6V Operation
o
Overall 8-Bit PWM LED Intensity Control
Global 16-Step Intensity Control
Individual 16-Step Intensity Controls
o
Two-Phase LED Blinking
o
High Output Current (50mA max Per Port)
o
Outputs are 5.5V-Rated Open Drain
o
Supports Hot Insertion
o
Inputs are Overvoltage Protected to 5.5V
o
Transition Detection with Interrupt Output
o
1.2µA (typ), 3.6µA (max) Standby Current
o
Small 4mm x 4mm TQFN Package
o
-40°C to +125°C Temperature Range
o
All Ports Can Be Configured as Inputs or Outputs
KIT
ATION
EVALU
E
BL
AVAILA
Features
o
400kbs, 2-Wire Serial Interface, 5.5V Tolerant
MAX7313
Ordering Information
PART
MAX7313ATG+
MAX7313AEG+
TEMP RANGE
-40°C to +125°C
-40°C to +125°C
PIN-PACKAGE
24 TQFN-EP*
24 QSOP
+Denotes
a lead(Pb)-free/RoHS-compliant package.
*EP
= Exposed Pad.
Pin Configurations
AD0
P15
P14
P13
TOP VIEW
P12
14
P11
13
12 P10
11 P9
10 P8
Applications
SCL 19
18
17
16
15
LCD Backlights
LED Status Indication
Portable Equipment
Keypad Backlights
RGB LED Drivers
Notebook Computers
SDA 20
V+ 21
INT/O16 22
AD1 23
AD2 24
+
1
P0
2
P1
3
P2
4
P3
5
P4
*EP
MAX7313ATG
9
8
7
GND
P7
P6
6
P5
Typical Application Circuit appears at end of data sheet.
TQFN
4mm x 4mm
*CONNECT EP TO GND
Pin Configurations continued at end of data sheet.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
