24W AC-DC Interchangeable Industrial Adaptor
GE24
series
■
Features :
Interchangeable AC plugs (plug kit sold separately)
Universal AC input / Full range
No load power consumption< 0.075W
Energy efficiency Level
Ⅵ
Comply with EISA 2007/DoE and EU ErP
Class
II
power (without earth pin)
Protections: Short circuit / Overload / Over voltage
Pass LPS
Fully enclosed plastic case
LED indicator for power on
2 years warranty
Interchangeable AC plug specifically for GE series
TYPE
Australian type
ORDER NO.
AC plug-AU
U.K type
AC plug-UK
European type
AC plug-EU
US type
AC plug-US
Mix four type
AC plug-MIX
SPECIFICATION
POWER SUPPLY MAIN BODY ORDER NO. GE24
I
05-P1J GE24
I
07-P1J GE24
I
09-P1J GE24
I
12-P1J GE24
I
15-P1J GE24
I
18-P1J GE24
I
24-P1J GE24
I
48-P1J
I I
I I
I I
I I
I I
I I
I I
SAFETY MODEL NO.
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
OUTPUT
RATED POWER (max.)
I I
I I
I I
I I
I I
I I
I I
GE24
I
05
Note.2
5V
GE24
I
07
7.5V
2.0A
0 ~ 2.0A
15W
75mVp-p
±5.0%
±1.0%
±5.0%
GE24
I
09
9V
2.22A
0 ~ 2.22A
20W
100mVp-p
±5.0%
±1.0%
±5.0%
GE24
I
12
12V
2.0A
0 ~ 2.0A
24W
120mVp-p
±3.0%
±1.0%
±3.0%
GE24
I
15
15V
1.6A
0 ~ 1.6A
24W
150mVp-p
±3.0%
±1.0%
±3.0%
GE24
I
18
18V
1.33A
0 ~ 1.33A
24W
180mVp-p
±3.0%
±1.0%
±3.0%
GE24
I
24
24V
1.0A
0 ~ 1.0A
24W
240mVp-p
±3.0%
±1.0%
±3.0%
GE24
I
48
48V
0.5A
0 ~ 0.5A
24W
300mVp-p
±3.0%
±1.0%
±3.0%
3.0A
0 ~ 3.0A
15W
RIPPLE & NOISE (max.)
Note.3
50mVp-p
VOLTAGE TOLERANCE
Note.4
±5.0%
LINE REGULATION
LOAD REGULATION
Note.5
±1.0%
Note.6
±5.0%
SETUP, RISE, HOLD UP TIME
4000ms, 100ms, 30ms / 230VAC
Note.7
90 ~ 264VAC
VOLTAGE RANGE
135 ~ 370VDC
FREQUENCY RANGE
INPUT
EFFICIENCY (Typ.)
AC CURRENT
INRUSH CURRENT (max.)
LEAKAGE CURRENT (max.)
OVERLOAD
PROTECTION
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
47 ~ 63Hz
81%
0.7A / 100VAC
83%
0.4A / 230VAC
4000ms, 100ms, 10ms / 115VAC at full load
85.5%
80A / 230VAC
86%
86%
87%
87.5%
89%
COLD START 40A / 100VAC
0.25mA / 240VAC
110% ~ 200% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
115% ~ 135% rated output voltage
Protection type : Clamp by zener diode
-10 ~ +50
℃
(Refer to "Derating Curve")
20% ~ 90% RH non-condensing
ENVIRONMENT STORAGE TEMP., HUMIDITY
-20 ~ +85
℃
, 10 ~ 95% RH
TEMP. COEFFICIENT
±
0.03% /
℃
(0 ~ 30
℃
)
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
VIBRATION
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
EMC
ISOLATION RESISTANCE
(Note. 8)
EMC EMISSION
EMC IMMUNITY
LIFE
OTHERS
MTBF
DIMENSION
PACKING
UL60950-1, CSA C22.2, TUV EN60950 -1, AS/NZS 60950.1, CCC GB4943 approved
I/P-O/P:4242VDC
I/P-O/P:100M Ohms / 500VDC / 25
℃
/ 70% RH
Compliance to EN55022, EN61000-3-2,3, FCC part15, GB9254 class B, GB17625.1
Compliance to EN61000-4-2,3,4,5,6,8,11, light industry level, criteria A
2 years : 100% load 30
℃
, 8 hours / day
100Khrs min.
MIL-HDBK-217F (25
℃
)
81*43*40.5mm (L*W*H)
134g ; 50pcs / 8.4kg / CARTON
See page 2 ; Other type available by customer requested
See page 2 ; Other type available by customer requested
DC OUTPUT PLUG
CONNECTOR CABLE
NOTE
1.All parameters are specified at 230VAC input, rated load, 25
℃
70% RH ambient.
2.DC voltage: The output voltage set at point measure by plug terminal & 50% load.
3.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.
4.Tolerance: includes set up tolerance, line regulation, load regulation.
5.Line regulation is measured from low line to high line at rated load.
6.Load regulation is measured from 10% to 100% rated load
7.Derating may be needed under low input voltage. Please check the derating curve for more details.
8.The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the
EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.
(as available on http://www.meanwell.com)
9.Main body unit and AC inlet plug should be ordered separately ; it needs to be used along with any of the AC inlet plug.
File Name:GE24-SPEC 2015-12-09
