2MBI600U2E-060

IGBT Module U-Series

Features

· High speed switching

· Voltage drive

· Low inductance module structure

600V / 600A 2 in one-package

2. Equivalent circuit

Equivalent Circuit Schematic

Applications

· Inverter for Motor drive

· AC and DC Servo drive amplifier

· Uninterruptible power supply

· Industrial machines, such as Welding machines

Maximum ratings and characteristics

Absolute maximum ratings (at Tc=25°C unless otherwise specified)

Item

Collector-Emitter voltage

Gate-Emitter voltage

Collector current

Symbol

CES

GES

-I

pulse

stg

iso

Conditions

Rating

650

±20

600

1200

600

1200

2400

+150

-40 to +125

2500

3.5

4.5

Unit

Continuous

1ms

Collector Power Dissipation

Junction temperature

Storage temperature

Isolation voltage between terminal and copper base *1

Screw Torque

Mounting *

Terminals *

1 device

°C

VAC

N·m

AC:1min.

1 :

All terminals should be connected together when isolation test will be done.

2 :

Recommendable value : Mounting 2.5 to 3.5N·m(M5 or M6), Terminal 3.5 to 4.5 N·m(M6)

Electrical characteristics (at Tj=25°C unless otherwise specified)

Item

Zero gate voltage collector current

Gate-Emitter leakage current

Gate-Emitter threshold voltage

Collector-Emitter saturation voltage

Symbols

CES

GES

GE(th)

CE(sat)

(terminal)

CE(sat)

(chip)

Input capacitance

Turn-on time

ies

r(i)

off

(terminal)

(chip)

Reverse recovery time

Lead resistance, terminal-chip*

R lead

Conditions

=0V, V

=600V

=0V, V

=±20V

=20V, I

=600mA

=15V, I

=600A Tj=25°C

Tj=125°C

Tj=25°C

Tj=125°C

=10V, V

=0V, f=1MHz

=300V

=600A

=±15V

= 4.7

Ω

=0V

=600A

Tj=25°C

Tj=125°C

Tj=25°C

Tj=125°C

=600A

Characteristics

Min.

Typ.

–

6.2

–

6.7

2.15

2.40

1.85

2.10

0.40

0.22

0.16

0.48

0.07

1.90

1.95

1.60

1.65

–

0.45

Unit

Max.

3.0

600

7.7

2.45

–

1.20

0.60

–

1.20

0.45

2.30

–

0.35

–

µs

mΩ

µs

Turn-off time

Forward on voltage

:Biggest internal terminal resistance among arm.

Thermal resistance characteristics

Items

Thermal resistance

Contact Thermal resistance

Symbols

Rth(j-c)

Rth(c-f)*

Conditions

IGBT

FWD

With thermal compound

Characteristics

Min.

Typ.

–

0.0167

Unit

Max.

0.052

0.086

–

°C/W

: This is the value which is defined mounting on the additional cooling fin with thermal compound.
