FUJITSU SEMICONDUCTOR
DATA SHEET
DS07-12602-1E
8-bit Proprietary Microcontrollers
CMOS
F
2
MC-8FX MB95110A
Series
MB95116A/F118AS/F118AW/FV100A-101
■
DESCRIPTION
The MB95110A series is general-purpose, single-chip microcontrollers. In addition to a compact instruction set,
the microcontrollers contain a variety of peripheral functions.
■
FEATURES
•
F
2
MC-8FX CPU core
Instruction set that is optimum to the controllers
• Multiplication and division instructions
• 16-bit arithmetic operation
• Bit test branch instruction
• Bit manipulation instructions etc.
•
Clock
• Main clock
• Main PLL clock
• Subclock (for dual clock product)
• Sub PLL clock (for dual clock product)
(Continued)
■
PACKAGES
48-pin plastic BCC
48-pin plastic-LQFP
(LCC-48P-M09)
(FPT-48P-M26)
MB95110A Series
(Continued)
•
Timer
• 8/16-bit compound timer
×
2 channels
• 8/16-bit PPG
×
2 channels
• 16-bit PPG
• Timebase timer
• Watch prescaler (for dual clock product)
•
LIN-UART
• Full duplex double buffer
• Clock asynchronous or synchronous serial transfer capable
•
UART/SIO
• Clock asynchronous or synchronous serial transfer capable
2
C*
•
I
• Built-in wake-up function
•
External interrupt
• Interrupt by edge detection (rising, falling, or both edges can be selected)
• Can be used to recover from low-power consumption modes.
•
10-bit A/D converter
• 10-bit resolution
•
Low-power consumption (standby mode)
• Stop mode
• Sleep mode
• Watch mode (for dual clock product)
• Timebase timer mode
•
I/O port: Max 40
• General-purpose I/O ports (Nch open drain) : 2 ports
• General-purpose I/O ports (CMOS)
: 38 ports
* : Purchase of Fujitsu I
2
C components conveys a license under the Philips I
2
C Patent Rights to use, these com-
ponents in an I
2
C system provided that the system conforms to the I
2
C Standard Specification as defined by
Philips.
2
MB95110A Series
■
PRODUCT LINEUP
Part number
Parameter
Type
ROM capacity
RAM capacity
Reset output
Option
Selectable
single/dual
-system*
2
Single-system
MB95116A
MASK product
32 Kbytes
1 Kbytes
2 Kbytes
No
Dual-system
Selectable
single/dual
-system*
1
MB95F118AS
MB95F118AW
MB95FV100A-101
EVA product
3.75 Kbytes
FLASH product
60 Kbytes
CPU functions
Number of basic instructions
Instruction bit length
Instruction length
Data bit length
Minimum instruction execution time
Interrupt processing time
: 136
: 8 bits
: 1 to 3 bytes
: 1, 8, and 16 bits
: 0.1
µs
(at internal 10 MHz)
: 0.9
µs
(at internal 10 MHz)
: 2 ports
: 38 ports
Ports
(Max 40 ports)
Timebase timer
Watchdog timer
Wild register
General-purpose I/O port (Nch open drain)
General-purpose I/O port (CMOS)
Interrupt cycle : 0.5 ms, 2.05 ms, 8.2 ms, 32.8 ms (at main oscillation clock 4 MHz)
Reset generated cycle
At main oscillation clock 10 MHz
: Minimum 105 ms
At sub oscillation clock 32.768 kHz (for dual clock product) : Minimum 250 ms
Capable of replacing 3 bytes of data
Master/slave sending and receiving
Bus error function and arbitration function
Detecting transmitting direction function
Start condition repeated generation and detection functions
Built-in wake-up function
Data transfer capable in UART/SIO
Full duplex double buffer, variable data length (5/6/7/8-bit), built-in baud rate generator
Transfer rate : 2400 bps to 125000 bps (at machine clock 10 MHz)
NRZ type transfer format, error detected function
LSB-first or MSB-first can be selected.
Clock synchronous (SIO) or clock asynchronous (UART) data transfer capable
Dedicated reload timer allowing a wide range of communication speeds to be set.
Capable of data transfer synchronous or asynchronous to clock signal.
LIN functions available as the LIN master or LIN slave.
8-bit or 10-bit resolution can be selected.
Each channel of the timer can be used as “8-bit timer
×
2 channels” or “16-bit timer
×
1 channel”.
Built-in timer function, PWC function, PWM function, capture function and square
waveform output
Count clock : 7 internal clocks and external clock can be selected.
(Continued)
Peripheral functions
I
2
C bus
UART/SIO
LIN-UART
A/D converter
(8 channels)
8/16-bit
compound timer
(2 channels)
3
MB95110A Series
(Continued)
Part number
Parameter
16-bit PPG
Peripheral functions
MB95116A
MB95F118AS
MB95F118AW
MB95FV100A-101
PWM mode or one-shot mode can be selected.
Counter operating clock : Eight selectable clock sources
Support for external trigger start
Each channel of the PPG can be used as “8-bit PPG
×
2 channels” or “16-bit PPG
×
1 channel”.
Counter operating clock : Eight selectable clock sources
8/16-bit PPG
(2 channels)
Watch counter
Count clock : Four selectable clock sources (125ms, 250ms, 500ms, or 1s)
(for dual clock product) Counter value can be set from 0 to 63. (Capable of counting for 1 minute)
Watch prescaler
Four selectable interval times (125 ms, 250 ms, 500 ms, or 1 s)
(for dual clock product)
External interrupt
(8 channels)
Interrupt by edge detection (rising, falling, or both edges can be selected)
Can be used to recover from standby modes.
Sleep, stop, watch, and timebase timer
Standby mode
*1 : Change by the switch on MCU board.
*2 : Specify clock mode when ordering MASK ROM.
4
MB95110A Series
■
SELECT OF OSCILLATION STABILIZATION WAIT TIME (MASK PRODUCT ONLY)
For the MASK product, you can set the mask option when ordering MASK ROM to select the initial value of main
clock oscillation stabilization wait time from among the following four values.
Note that the EVA and FLASH products are fixed their initial value of main clock oscillation stabilization wait time
at the maximum value.
Selection of oscillation stabilization wait time
(2
2
−
2) /F
CH
(2
12
−
2) /F
CH
(2
13
−
2) /F
CH
(2
14
−
2) /F
CH
Remarks
0.5
µs
(at main oscillation clock 4 MHz)
Approx. 1.02 ms (at main oscillation clock 4 MHz)
Approx. 2.05 ms (at main oscillation clock 4 MHz)
Approx. 4.10 ms (at main oscillation clock 4 MHz)
■
PACKAGES AND CORRESPONDING PRODUCTS
Part number
Package
LCC-48P-M09
FPT-48P-M26
BGA-224P-M08
: Available
: Unavailable
MB95116A
MB95F118AS
MB95F118AW
MB95FV100A-101
5
