GS81302Q10E-300T datasheet, PDF

Datasheet> All Categories > storage> storage> GS81302Q10E-300T

GS81302Q10E-300T: DescriptionQDR SRAM, 16MX9, 0.45ns, CMOS, PBGA165, FPBGA-165; Categorystorage storage; File Size370KB，28 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/

Download Datasheet Parametric View All

GS81302Q10E-300T Overview

QDR SRAM, 16MX9, 0.45ns, CMOS, PBGA165, FPBGA-165

GS81302Q10E-300T Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	GSI Technology
Parts packaging code	BGA
package instruction	LBGA,
Contacts	165
Reach Compliance Code	compliant
ECCN code	3A991.B.2.B
Maximum access time	0.45 ns
Other features	PIPELINED ARCHITECTURE
JESD-30 code	R-PBGA-B165
length	17 mm
memory density	150994944 bit
Memory IC Type	QDR SRAM
memory width	9
Number of functions	1
Number of terminals	165
word count	16777216 words
character code	16000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	16MX9
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	1.5 mm
Maximum supply voltage (Vsup)	1.9 V
Minimum supply voltage (Vsup)	1.7 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
width	15 mm

Preview

Download Datasheet

View All

GS81302Q07/10/19/37E-318/300/250/200

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.0 clock Latency

• Simultaneous Read and Write SigmaQuad™ Interface

• JEDEC-standard pinout and package

• Dual Double Data Rate interface

• Byte Write controls sampled at data-in time

• On-Die Termination (ODT) on Data (D), Byte Write (BW),

and Clock (K, K) inputs

• Burst of 2 Read and Write

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• Data Valid Pin (QVLD) Support

• IEEE 1149.1 JTAG-compliant Boundary Scan

• 165-bump, 15 mm x 17 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

144Mb SigmaQuad-II+

Burst of 2 SRAM

318 MHz–200 MHz

1.8 V V

1.8 V and 1.5 V I/O

are just one element in a family of low power, low voltage

HSTL I/O SRAMs designed to operate at the speeds needed to

implement economical high performance networking systems.

Clocking and Addressing Schemes

The GS81302Q07/10/19/37E SigmaQuad-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Each internal read and write operation in a SigmaQuad-II+ B2

RAM is two times wider than the device I/O bus. An input data

bus de-multiplexer is used to accumulate incoming data before

it is simultaneously written to the memory array. An output

data multiplexer is used to capture the data produced from a

single memory array read and then route it to the appropriate

output drivers as needed. Therefore the address field of a

SigmaQuad-II+ B2 RAM is always one address pin less than

the advertised index depth (e.g., the 16M x 8 has an 8M

addressable index).

SigmaQuad™ Family Overview

The GS81302Q07/10/19/37E are built in compliance with the

SigmaQuad-II+ SRAM pinout standard for Separate I/O

synchronous SRAMs. They are 150,994,944-bit (144Mb)

SRAMs. The GS81302Q07/10/19/37E SigmaQuad SRAMs

Parameter Synopsis

-318

tKHKH

tKHQV

3.145 ns

0.45 ns

-300

3.3 ns

0.45 ns

-250

4.0 ns

0.45 ns

-200

5.0 ns

0.45 ns

Rev: 1.02e 5/2012

1/28

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
