Axial Coated Inductors
AC30
Dimensions:
Inches
(mm)
24AWG
1.15
NOMINAL
(29)
0.394
MAX.
(10.01)
1.15
NOMINAL
(29)
Allied
Part
Number
Inductance Tolerance
(%)
(µh)
Q
Min.
Test
Freq.
(MHz)
SRF
Min.
(MHz)
DCR
Max.
(Ω)
Rated
Current
(mA)
Features
0.157
(3.99)
MAX.
•
Incorporation of a special lead wire
structure entirely eliminates defects
inherent in existing axial lead type
products and prevents lead breakage.
•
The special magnetic core structure
permits the product to have reduced
size, high "Q" and self resonant
frequencies.
•
Treated with epoxy resin coating for
humidity resistance to ensure longer
life.
•
Heat resistant adhesives and special
structural design for effective open
circuit measurement.
Electrical
Inductance Range:
.10µh to 1000µh.
Tolerance:
10% over entire range. Tighter
tolerances available
Temp. Rise:
20°C.
Ambient Temp.:
80°C.
Rated Temp Range:
-20 to +100°C.
Dielectric Withstanding Voltage:
250 Volts
R.M.S.
Rated Current:
Based on temp rise.
AC30-R10K-RC
AC30-R12K-RC
AC30-R15K-RC
AC30-R18K-RC
AC30-R22K-RC
AC30-R27K-RC
AC30-R33K-RC
AC30-R39K-RC
AC30-R47K-RC
AC30-R56K-RC
AC30-R68K-RC
AC30-R82K-RC
AC30-1R0K-RC
AC30-1R2K-RC
AC30-1R5K-RC
AC30-1R8K-RC
AC30-2R2K-RC
AC30-2R7K-RC
AC30-3R3K-RC
AC30-3R9K-RC
AC30-4R7K-RC
AC30-5R6K-RC
AC30-6R8K-RC
AC30-8R2K-RC
AC30-100K-RC
AC30-120K-RC
AC30-150K-RC
AC30-180K-RC
AC30-220K-RC
AC30-270K-RC
AC30-330K-RC
AC30-390K-RC
AC30-470K-RC
AC30-560K-RC
AC30-680K-RC
AC30-820K-RC
AC30-101K-RC
AC30-121K-RC
AC30-151K-RC
AC30-181K-RC
AC30-221K-RC
AC30-271K-RC
AC30-331K-RC
AC30-391K-RC
AC30-471K-RC
AC30-561K-RC
AC30-681K-RC
AC30-821K-RC
AC30-102K-RC
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
55
55
60
65
65
70
70
75
80
85
75
70
65
40
55
55
50
45
40
40
35
30
70
70
70
70
65
65
65
60
60
55
55
50
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.252
470
450
430
410
380
340
300
280
250
230
210
172
157
144
131
121
110
100
94
86
80
74
58
53
45
30
20
14
9.9
7.6
6.3
6.3
6.3
6.2
5.7
5.3
4.8
3.8
3.5
3.3
3.0
2.8
2.6
2.4
2.25
2.1
1.95
1.85
1.4
0.04
0.06
0.07
0.07
0.08
0.09
0.10
0.12
0.16
0.18
0.22
0.24
0.09
0.10
0.23
0.25
0.28
0.30
0.34
0.37
0.39
0.43
0.48
0.52
0.58
0.63
0.72
0.77
0.84
0.94
1.03
1.12
1.22
1.34
1.47
1.62
1.80
3.70
4.20
4.60
5.10
5.80
6.40
7.00
7.70
8.5
9.4
12.0
17.4
900
900
890
890
880
800
750
680
650
600
550
980
920
880
830
790
750
720
670
640
620
590
550
530
500
480
460
430
410
390
370
350
340
320
305
290
275
185
175
165
155
145
137
133
126
120
113
100
100
Mechanical
Terminal Tensile Strength:
1.0 kg min.
Terminal Bending Strength:
.3 kg min.
Physical
Marking (on reel):
Manufacturers name,
Part number, Quantity,
Marking:
4 band color code.
Packaging:
5000 pieces per Ammo
Pack.
For Tape and Reel packaging please
add ”-TR” to the part number.
All specifications subject to change without notice.
