FS50R06YE3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> FS50R06YE3

FS50R06YE3: DescriptionIGBT-modules; CategoryDiscrete semiconductor The transistor; File Size306KB，8 Pages; ManufacturerEUPEC [eupec GmbH]

Download Datasheet Parametric View All

FS50R06YE3 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	FS50R06YE3	-	-	View	Buy Now

FS50R06YE3 Overview

IGBT-modules

FS50R06YE3 Parametric

Parameter Name	Attribute value
Maker	EUPEC [eupec GmbH]
package instruction	MODULE-23
Reach Compliance Code	unknow
Shell connection	ISOLATED
Maximum collector current (IC)	60 A
Collector-emitter maximum voltage	600 V
Configuration	COMPLEX
JESD-30 code	R-XUFM-X23
Number of components	6
Number of terminals	23
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Polarity/channel type	N-CHANNEL
Certification status	Not Qualified
surface mount	NO
Terminal form	UNSPECIFIED
Terminal location	UPPER
transistor applications	POWER CONTROL
Transistor component materials	SILICON
Nominal off time (toff)	265 ns
Nominal on time (ton)	43 ns

Preview

Download Datasheet

View All

Technische Information / technical information

IGBT-Module

IGBT-modules

FS50R06YE3

()
