Crimp
DV
CONNECTOR
Disconnectable Crimp style connectors
5.0mm
(.197") pitch
Features –––––––––––––––––––––––
• Secure mounting
The housing look feature secures the connector with the
header, ensuring that a stable connection is maintained during
vibration.
• Twin-beam contacts
Each contact has two wiping areas, ensuring a stable and
reliable connection.
• Housing lances
Specifications ––––––––––––––––––
• Current rating: 2.0A AC, DC (AWG #22)
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/10mΩ max.
After environmental testing/20mΩ max.
• Insulation resistance:
1,000MΩ min.
• Withstanding voltage: 1,500V AC/minute
• Applicable wire: AWG #24 to #20
• Applicable PC board thickness: 1.6mm(.063")
* Contact JST for details.
V
JS
T
V
1
2
3
4
5
6
D
JS
T
Standards –––––––––––––––––––––
Recognized file No. E60389
Certified file No. LR20812
95
DV
CONNECTOR
Contact –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Model No.
SDY-01T-P1.6ASV
Applicable wire
mm
2
AWG#
0.2 to 0.5
24 to 20
Insulation O.D.
min(in.)
1.5 to 2.7(.059 to .106)
Q´ty /
reel
6,000
Material and Finish
12.9(.508)
Phosphor bronze, tin-plated
3.5(.138)
2.5(.098)
7.3(.287)
4.4(.173)
Housing –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
C
Cir-
cuits
2
19.4(.764)
Model No.
DVR-02V-S
DVR-03V-S
DVR-04V-S
DVR-05V-S
DVR-06V-S
Dimensions mm(in.)
A
7.5(1.295)
12.5(1.492)
17.5(1.689)
22.5(1.886)
27.5(1.083)
B
12.5(1.492)
17.5(1.689)
22.5(1.886)
27.5(1.083)
32.5(1.280)
C
21.7(1.854)
26.7(1.051)
31.7(1.248)
36.7(1.445)
41.7(1.642)
Q´ty /
bag
500
500
500
500
500
3
4
5
6
B
5.3
(.209)
6.3
(.248)
Material
Nylon 66, UL94V-0, natural (white)
5(.197) 5(.197) 5(.197) 5(.197) 7.5(.295)
A
2.5(.098)
Header ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Top entry type
1.57(.062) dia.
4
4.4
(.173) (.157) 8.1(.319)
Model No.
B
A
Dimensions mm(in.)
A
7.5(1.295)
12.5(1.492)
17.5(1.689)
22.5(1.886)
27.5(1.083)
Q´ty / box
Top
entry
type
500
500
250
250
200
Cir-
cuits
2
16.5(.650)
Top
entry
type
B02B-DVS
B03B-DVS
B04B-DVS
B05B-DVS
B06B-DVS
Side
entry
type
S02B-DVS
S03B-DVS
–
–
–
B
12.5(1.492)
17.5(1.689)
22.5(1.886)
27.5(1.083)
32.5(1.280)
Side
entry
type
250
250
–
–
–
3
4
5
6
1.57(.062) dia.
Side entry type
A
5(.197) 7.5(.295)
7.3(.287)
2.5(.098)
7.3(.287)
6.0(.236) 9.0(.354)
Material and Finish
Pin: Brass, copper-undercoated, tin/lead-plated
Wafer: Glass-filled PBT, UL94V-0ÅA, natural (white)
11.3(.445)
96
11.3(.445)
DV
CONNECTOR
PC board layout
(viewed from soldering side)
and Assembly layout ––––––––––––––––––
Top entry type
6.3(.248)
7.5
±
0.05 5.0
±
0.05 4.0min.
(.295
±
.002) (.197
±
.002) (.157)
4.0min.
(.157)
7.5
±
0.05 5.0
±
0.05 4.0min.
(.295
±
.002) (.197
±
.002) (.157)
[23.75(.935)]
[21.8(.858)]
7.0min
(.276)
[7.77(.306)]
Side entry type
0.1
1.70
+ 0
.004
(.067
+ 0
)dia.
0.1
1.70
+ 0
-
.004
(.067
+ 0
)dia.
-
Note:
1. Tolerances are non-Cumulative :±0.05mm (±.002") for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method.
The dimensions above should serve as a guideline. Contact JST for details.
97
