140MHz SAW Filter
6MHz Bandwidth
Part Number: LBS140A11
www. sipatsaw.com
SIPAT Co., Ltd.
Features
For IF SAW filter
High attenuation
Single-ended operation
Dual In-line Package
RoHS compliant (2002/95/EC), Pb-free
Specifications
Parameter
Center Frequency
Insertion Loss
3 dB Bandwidth
Passband Variation
Absolute Delay
f0±3.45MHz
f0±3.65MHz
Ultimate Rejection
f0±4.05MHz
f0±8.05MHz
f0±18.05MHz
Material Temperature coefficient
Substrate Material
Ambient Temperature
Operating Temperature Range
Storage Temperature Range
DC Voltage
Input Power
ESD Class
Package Size
Notes:
1.
2.
All specifications are based on the test circuit shown;
In production, all specifications are measured by Agilent Network analyzer and full 2 port calibration at room
temperature;
3.
Electrical margin has been built into the design to account for the variations due to temperature drift and
manufacturing tolerances;
4.
This is the optimum impedance in order to achieve the performance show.
Unit
MHz
dB
MHz
dB
usec
dB
dB
dB
dB
dB
KHz/°C
-
°C
°C
°C
V
dBm
-
Minimum
139.85
-
6
-
-
35
45
48
50
52
Typical
140
26.6
6.06
0.7
3.33
40
51
56
55
64
0.14
Qz
25
Maximum
140.15
30
-
1.5
4
-
-
-
-
-
-40
-45
-
-
0
+85
+105
-
-
1A
10
DIP3512 (35.0x12.8x4.7mm3)
SIPAT Co., Ltd.
( CETC No.26 Research Institute )
#14 Nanping Huayuan Road,
Chongqing, China, 400060
Tel: +86-23-62808818
Part Number
Rev. Date
Ver.
LBS140A11
2010-11-26
1.1
Page
1/3
Fax: +86-23-62808382
www.sipatsaw.com / sawmkt@sipat.com
China Electronics Technology Group Corporation
No.26 Research Institute
140MHz SAW Filter
6MHz Bandwidth
Part Number: LBS140A11
www. sipatsaw.com
SIPAT Co., Ltd.
Matching Configuration
L1
L2
L1=120nH L2=82nH
OUTPUT
50
Ω
C2
Notes - Component values may change depending
on board layout.
INPUT
50
Ω
C1
C1=39pF
C2=47pF
Source/Load Impedance=50 ohm
Package Dimension
35.00 0.5
12.80 0.5
SIPAT
LBS140A11
XXYYZZ
Pad Configuration:
Input
Output
1
5
Ground All Others
Marking Configuration:
1) SIPAT: Manufacturer Name
2) LBS140A11: Part Number
3) XXYY: Date(Year/month)
4) ZZ: Identified Code
4.7
4.5
0.45 0.05
2.54 0.2
7.62 0.2
3
6
Package: DIP3512
SIPAT Co., Ltd.
( CETC No.26 Research Institute )
#14 Nanping Huayuan Road,
Chongqing, China, 400060
Tel: +86-23-62808818
2
1
4
5
25.40 0.2
2.54 0.2
Unit: mm
Part Number
Rev. Date
Ver.
LBS140A11
2010-11-26
1.1
Page
2/3
Fax: +86-23-62808382
www.sipatsaw.com / sawmkt@sipat.com
China Electronics Technology Group Corporation
No.26 Research Institute
140MHz SAW Filter
6MHz Bandwidth
Part Number: LBS140A11
www. sipatsaw.com
SIPAT Co., Ltd.
Typical Performance
Frequency Respond
Type Performance
-16.6433
-26.6433
-36.6433
-26.1433
-25.1433
Passband Respond
-25.6433
-46.6433
Magnitude(dB)
-56.6433
-66.6433
-76.6433
-86.6433
-28.1433
-26.6433
-27.1433
-27.6433
-96.6433
-106.6433
-116.6433
120
-28.6433
-29.1433
125
130
135
140
145
Frequency(MHz)
150
155
160
134
136
138
140
142
144
146
Horizontal: 5MHz/Div
Vertical: 10dB/Div
Horizontal: 2MHz/Div
Vertical: 0.5dB/Div
Group Delay Variation(f0±3MHz)
Type Performance
3600
15
Phase Linearity(f0±3MHz)
Type Performance
3500
10
5
3400
X: 140
Y: -0.06481
X: 143
Y: 1.644
Group Delay Time(ns)
3300
X: 140
Y: 3321
Degree(deg)
X: 137
Y: 3314
X: 143
Y: 3308
0
X: 137
Y: -1.965
-5
3200
-10
-15
3100
-20
3000
135
136
137
138
139
140
Frequency(MHz)
141
142
143
144
145
-25
135
136
137
138
139
140
Frequency(MHz)
141
142
143
144
145
Horizontal: 1MHz/Div
Vertical: 100ns/Div
Horizontal: 1MHz/Div
Vertical: 5deg/Div
Smith Chart S11
+j1.0
+j0.5
+j2.0
Smith Chart S22
+j1.0
+j0.5
+j2.0
+j0.2
+j5.0
+j0.2
+j5.0
0.2
0.5
1.0
2.0
5.0
0.2
0.5
1.0
2.0
0.0
∞
5.0
0.0
∞
-j0.2
-j5.0
-j0.2
-j5.0
-j0.5
-j1.0
-j2.0
-j0.5
-j1.0
-j2.0
SIPAT Co., Ltd.
( CETC No.26 Research Institute )
#14 Nanping Huayuan Road,
Chongqing, China, 400060
Tel: +86-23-62808818
Part Number
Rev. Date
Ver.
LBS140A11
2010-11-26
1.1
Page
3/3
Fax: +86-23-62808382
www.sipatsaw.com / sawmkt@sipat.com
