FERRITE D-SUBMINIATURE
KYCON
RoHS
RoHS
KF22X Series
Documentation &
Ordering Information
Drawing
Sample
Stock
Email
CofC
RFQ
Kycon Part #
KF22X-E9P-HJM
Part Number Builder
KF22X
KF22X
B
E9
Shell
Size
S
P
Contact
Type
H
JM
Series
KF22X Series
Right Angle
PCB Mount .318" Footprint with Ferrite
Pictured with Board Lock Option, Dimensions in mm [In]
C
2.84 [.112]
Series
Front Panel Plating
PCB
Mounting Mounting Option
Options Options
KF22X - D-Subminiature Connector,.318"
Footprint with Ferrite
KF22X
B
A, A1
3.18 [.125]
Shell Size-Contact Option
E - 9 Contacts
E
A
A - 15 Contacts
B
B - 25 Contacts
C
- 37 Contacts
C
Contact Type
P - Pin Contact (Plug)
P
S - Socket Contact (Receptacle)
S
PC Board Mounting Option
N
N Option
Option
2.77 [.109]
12.55 [.494]
5.9 Plug,
6.0 Socket
9.53 [.375]
12.40 [.488]
8.36 Plug Interior,
7.90 Socket Exterior
0.80 [.031]
NV
Option
NV
Option
Edge
Hole
Inner
Hole
Ferrite 2.8mm
2.84 [.112]
8.08 [.318]
1.385 [.054]
Grounding
Bracket
4 Prong
Grounding Bracket
2-Ø3.05
[.120]
2.77 [.109]
Ø1.09 [.043]
8.08 [.318]
Front Panel Mounting Option
Standard
Standard
(4-40)Riveted
Threaded Insert
5.00
.197
1.45 [.057]
2.84 [.112]
J Option
J Option
R Option
R Option
Ø5.0
.197
6.00
.236
T Option
T Option
JM Option
JM Option
M3
5.00
.197
B
(4-40) Round Jack Screws Riveted Non-Threaded
Insert 3.18/.125" Dia.
Riveted to Connector
Recommended PCB Layout
Shell
Size
9
(E)
15
(A)
25
(B)
37
(C)
A
±.010
±0.25
.643
16.33
.971
24.66
1.511
38.38
2.159
54.84
AI
±.010
±0.25
.666
16.92
.994
25.25
1.534
38.96
2.182
55.42
B
±.005
±0.13
.984
24.99
1.312
33.32
1.852
47.04
2.500
63.50
C
±.015
±0.38
1.213
30.81
1.541
39.14
2.088
53.04
2.729
69.32
(Top View)
4-40
In
mm
Blank
- Gold Flash
Blank
15
15 - 15
µ
” Gold
30
30 - 30
µ
” Gold
Plating Option
(4-40)Riveted Threaded
Insert with 4-40 Hex.
JS1000 Jack Screws Installed
to Connector
(4-40)Riveted Threaded
Insert with M3/4-40 Hex.
JS-M3131 Jack Screws
Installed
to Connector
Contact Kycon for other Options
Click here for all KF22X series part number list
Click here for Performance Specification
2007
A = Exterior of Female Shell (S) A1 = Interior of Male Shell (P)
Click here for FERRITE D-SUBMINIATURE CONNECTORS
KYCON, Inc. • Tel: +1 408-494-0330 • US: 1-888-KYCON-22 • Fax: +1 408-494-0325 • www.kycon.com
