PRODUCT INFORMATION
H07Z-K 90°C
Harmonised; halogen-free to protect human life, the environment and material assets
H07Z-K 90°C, HAR, halogen-free single core, harmonised, for wiring in control cabinets, nominal voltage 450/750V
Info
Halogen-free and harmonised (HAR)
For expanded ambient temperatures
and higher conductor cross-sections
see ÖLFLEX® HEAT 125 SC
Halogen-free
Benefits
Protection of human life and the environment thanks to the avoidance of the formation of acid in case of fire
Time-saving assembly
Application range
For wiring of lamps, devices, switchgear cabinets and distribution boxes
For installation in tubes, on, in and under plaster as well as in closed installation ducts
In building with a high density of people or valuable assets
For use in dry rooms
For expanded ambient temperatures
and higher conductor cross-sections
see ÖLFLEX® HEAT 125 SC
Product features
The insulation material is halogen-free and free of other materials which could release toxic gases in the event of fire
Low amount of corrosive gases in the event of fire
Low smokes/low smoke density in the event of fire according to IEC 61034
Flame-retardant according IEC 60332-1-2
Last Update (04.12.2016)
©2016 Lapp Group - Technical changes reserved
Product Management www.lappkabel.de
You can find the current technical data in the corresponding data sheet.
PN 0456 / 02_03.16
PRODUCT INFORMATION
H07Z-K 90°C
Norm references / Approvals
<HAR> cable type certification acc. EN 50525-3-41
No cable type certified core insulation colours according to EN 50525-1/ VDE 0285-525-1: transparent, green (single colour),
yellow (single colour), all double colours (except of green-yellow and yellow-green)
Product Make-up
Fine-wire strand made of bare copper wires
Core insulation: Halogen-free
Technical Data
Classification:
ETIM 5.0 Class-ID: EC000993
ETIM 5.0 Class-Description: Single core cable
Fine wire according to VDE 0295 Class 5/ IEC 60228 Class 5
According to EN 50565-1
OD ≤ 8 mm: 4 x OD*/2 x OD**;
8 < OD ≤ 12 mm: 5 x OD*/3 x OD**;
OD > 12 mm: 6 x OD*/4 x OD**
U
0
/U: 450/ 750 V
2500 V
VDE 0298-4
EN 50565-1/ VDE 0298-565-1
During installation: -5°C bis +90°C
Fixed installation: -40°C bis +90°C
Conductor stranding:
Minimum bending radius:
Nominal voltage:
Test voltage:
Current rating:
Temperature range:
Note
Unless specified otherwise, the shown product values are nominal values. Detailed values (e.g. tolerances) are available upon
request.
Copper price basis: EUR 150/100 kg. Refer to catalogue appendix T17 for the definition and calculation of copper-related
surcharges.
Packaging size: Coil ≤ 30 kg, otherwise drum
Photographs are not to scale and do not represent detailed images of the respective products.
* Prices are net prices without VAT and surcharges. Sale to business customers.
*for conventional use, **for careful bending; "OD" = outer diameter
The outer diameters stated in the part number table are maximum values.
Last Update (04.12.2016)
©2016 Lapp Group - Technical changes reserved
Product Management www.lappkabel.de
You can find the current technical data in the corresponding data sheet.
PN 0456 / 02_03.16
Powered by TCPDF (www.tcpdf.org)
H07Z-K 90°C
Article number
4726001
4726001K
4726121
4726121K
4726031
4726031K
4726011
4726011K
4726061
4726061K
4726021
4726021K
4726141
4726141K
4726091
4726091K
4726071
4726071K
4726111
4726111K
4726051
4726051K
4726041
4726041K
4726081
4726081K
4726261K
4726002
4726002K
4726122
4726122K
4726032
4726032K
4726012
Conductor cross-section Outer diameter (mm)
(mm²)
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
2.8 - 3.5
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
Core colour
green/yellow
green/yellow
green
green
brown
brown
black
black
grey
grey
blue
blue
dark blue
dark blue
orange
orange
violet
violet
yellow
yellow
white
white
red
red
pink
pink
blue/white
green/yellow
green/yellow
green
green
brown
brown
black
m/ring
100
1500
100
1500
100
1500
100
1500
100
1500
100
1500
100
1500
100
1500
100
1500
100
1500
100
1500
100
1500
100
1500
1500
100
900
100
900
100
900
100
Copper index (kg/km)
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
14.4
24
24
24
24
24
24
24
Weight (kg/km)
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
32
32
32
32
32
32
32
Last Update (04.12.2016)
©2016 Lapp Group - Technical changes reserved
Product Management www.lappkabel.de
You can find the current technical data in the corresponding data sheet.
PN 0456 / 02_03.16
PRODUCT INFORMATION
Powered by TCPDF (www.tcpdf.org)
H07Z-K 90°C
Article number
4726012K
4726062
4726062K
4726022
4726022K
4726142
4726142K
4726092
4726092K
4726072
4726072K
4726112
4726112K
4726052
4726052K
4726042
4726042K
4726082
4726082K
4726262K
4726003
4726003K
4726123
4726123K
4726033
4726033K
4726013
4726013K
4726063
4726063K
4726023
4726023K
4726143
4726143K
Conductor cross-section Outer diameter (mm)
(mm²)
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
4
4
4
4
4
4
4
4
4
4
4
4
4
4
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.4 - 4.3
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
Core colour
black
grey
grey
blue
blue
dark blue
dark blue
orange
orange
violet
violet
yellow
yellow
white
white
red
red
pink
pink
blue/white
green/yellow
green/yellow
green
green
brown
brown
black
black
grey
grey
blue
blue
dark blue
dark blue
m/ring
900
100
900
100
900
100
900
100
900
100
900
100
900
100
900
100
900
100
900
900
100
600
100
600
100
600
100
600
100
600
100
600
100
600
Copper index (kg/km)
24
24
24
24
24
24
24
24
24
24
24
24
24
24
24
24
24
24
24
24
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
Weight (kg/km)
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
45
45
45
45
45
45
45
45
45
45
45
45
45
45
Last Update (04.12.2016)
©2016 Lapp Group - Technical changes reserved
Product Management www.lappkabel.de
You can find the current technical data in the corresponding data sheet.
PN 0456 / 02_03.16
PRODUCT INFORMATION
Powered by TCPDF (www.tcpdf.org)
H07Z-K 90°C
Article number
4726093
4726093K
4726073
4726073K
4726113
4726113K
4726053
4726053K
4726043
4726043K
4726083
4726083K
4726004
4726004K
4726124
4726124K
4726034
4726034K
4726014
4726014K
4726064
4726064K
4726024
4726024K
4726144
4726144K
4726094
4726094K
4726074
4726074K
4726114
4726114K
4726054
4726054K
Conductor cross-section Outer diameter (mm)
(mm²)
4
4
4
4
4
4
4
4
4
4
4
4
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
3.9 - 4.9
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
4.4 - 5.5
Core colour
orange
orange
violet
violet
yellow
yellow
white
white
red
red
pink
pink
green/yellow
green/yellow
green
green
brown
brown
black
black
grey
grey
blue
blue
dark blue
dark blue
orange
orange
violet
violet
yellow
yellow
white
white
m/ring
100
600
100
600
100
600
100
600
100
600
100
600
100
400
100
400
100
400
100
400
100
400
100
400
100
400
100
400
100
400
100
400
100
400
Copper index (kg/km)
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
57.6
Weight (kg/km)
45
45
45
45
45
45
45
45
45
45
45
45
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
Last Update (04.12.2016)
©2016 Lapp Group - Technical changes reserved
Product Management www.lappkabel.de
You can find the current technical data in the corresponding data sheet.
PN 0456 / 02_03.16
PRODUCT INFORMATION
