MAX6443US26L

Description
uP Reset Circuits with Long Manual Reset Setup Period
Categoryunclassified
File Size154KB,13 Pages
ManufacturerMaxim
Websitehttps://www.maximintegrated.com/en.html
Download Datasheet View All

MAX6443US26L Overview

uP Reset Circuits with Long Manual Reset Setup Period

19-2656; Rev 3; 6/10
µP Reset Circuits with Long Manual Reset
Setup Period
General Description
The MAX6443–MAX6452 low-current microprocessor
reset circuits feature single or dual manual reset inputs
with an extended setup period. Because of the extend-
ed setup period, short switch closures (nuisance resets)
are ignored.
On all devices, the reset output asserts when any of the
monitored supply voltages drops below its specified
threshold. The reset output remains asserted for the
reset timeout period (210ms typ) after all monitored
supplies exceed their reset thresholds. The reset output
is one-shot pulse asserted for the reset timeout period
(140ms min) when selected manual reset input(s) are
held low for an extended setup timeout period. These
devices ignore manual reset transitions of less than the
extended setup timeout period.
The MAX6443–MAX6448 are single fixed-voltage µP
supervisors. The MAX6443/MAX6444 have a single
extended manual reset input. The MAX6445/MAX6446
have two extended manual reset inputs. The MAX6447/
MAX6448 have one extended and one immediate manual
reset input.
The MAX6449–MAX6452 have one fixed-threshold µP
supervisor and one adjustable-threshold µP supervisor.
The MAX6449/MAX6450 have two delayed manual
reset inputs. The MAX6451/MAX6452 have one delayed
and one immediate manual reset input.
The MAX6443–MAX6452 have an active-low
RESET
with push-pull or open-drain output logic options. These
devices, offered in small SOT packages, are fully guar-
anteed over the extended temperature range (-40°C to
+85°C).
Features
o
Single- or Dual-Supply Voltage Monitors
o
Precision Factory-Set Reset Thresholds from
1.6V to 4.6V
o
Adjustable Threshold to Monitor Voltages Down
to 0.63V (MAX6449–MAX6452)
o
Single or Dual Manual Reset Inputs with Extended
Setup Period
o
Optional Short Setup Time Manual Reset Input
(MAX6447/MAX6448 and MAX6451/MAX6452)
o
Immune to Short Voltage Transients
o
Low 6µA Supply Current
o
Guaranteed Valid Reset Down to V
CC
= 1.0V
o
Active-Low
RESET
(Push-Pull or Open-Drain)
Outputs
o
140ms (min) Reset Timeout Period
o
Small SOT143 and SOT23 Packages
MAX6443–MAX6452
Ordering Information
PART
MAX6443US_
_ _-T
MAX6444US_
_ _-T
TEMP RANGE
-40°C to +85°C
-40°C to +85°C
PIN-PACKAGE
4 SOT143
4 SOT143
Applications
Set-Top Boxes
Consumer Electronics
DVD Players
Cable/DSL Modems
MP3 Players
Industrial Equipment
Automotive
Medical Devices
Note:
The first “_ _ ” is a placeholder for the threshold voltage
level of the devices. A desired threshold level is set by the two-
number suffix found in Table 1. The third "_" is a placeholder
for the manual reset setup period of the devices. A desired
setup period is set by the letter suffix found in Table 2. All
devices are available in tape-and-reel only. There is a 2500-
piece minimum order increment for standard versions (Table
2). Sample stock is typically held on standard versions only.
Nonstandard versions require a minimum order increment of
10,000 pieces. Contact factory for availability.
Devices are available in both leaded and lead-free packaging.
Specify lead-free by replacing “-T” with “+T” when ordering.
Pin Configurations
TOP VIEW
GND
1
4
V
CC
MAX6443
MAX6444
RESET
2
3
MR1
SOT143
Pin Configurations continued at end of data sheet.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
