NRSX272M35V16X35TRF datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> NRSX272M35V16X35TRF

NRSX272M35V16X35TRF: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 35V, 20% +Tol, 20% -Tol, 2700uF, Through Hole Mount, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components capacitor; File Size588KB，6 Pages; ManufacturerNichicon; Websitehttp://www.nichicon.co.jp; Environmental Compliance

Download Datasheet Parametric View All

NRSX272M35V16X35TRF Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 35V, 20% +Tol, 20% -Tol, 2700uF, Through Hole Mount, RADIAL LEADED, ROHS COMPLIANT

NRSX272M35V16X35TRF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Nichicon
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	2700 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	16 mm
dielectric materials	ALUMINUM (WET)
JESD-609 code	e3
leakage current	0.945 mA
length	35 mm
Installation features	THROUGH HOLE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package shape	CYLINDRICAL PACKAGE
Package form	Radial
method of packing	TR
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	35 V
ripple current	2295 mA
series	NRSX(35V)
surface mount	NO
Delta tangent	0.15
Terminal surface	Matte Tin (Sn)
Terminal pitch	7.5 mm
Terminal shape	WIRE

Preview

Download Datasheet

View All

Miniature Aluminum Electrolytic Capacitors

VERY LOW IMPEDANCE AT HIGH FREQUENCY, RADIAL LEADS,

POLARIZED ALUMINUM ELECTROLYTIC CAPACITORS

FEATURES

• VERY LOW IMPEDANCE

includes all homogeneous materials

• LONG LIFE AT 105°C (1000 ~ 7000 hrs.)

*See Part Number System for Details

• HIGH STABILITY AT LOW TEMPERATURE

• IDEALLY SUITED FOR USE IN SWITCHING POWER SUPPLIES &

..CONVERTORS

CHARACTERISTICS

NRSX Series

RoHS

Compliant

Rated Voltage Range

Capacitance Range

Operating Temperature Range

Capacitance Tolerance

After 1 min.

Max. Leakage Current @ (20

After 2 min.

Max. Tan

@ 120Hz/20°C

Low Temperature Stability

Impedance Ratio @ 120Hz

Load Life Test at Rated W.V. & 105°C

7,000 Hours: 16 ~ 18

∅

5,000 Hours: 12.5

∅

4,000 Hours: 10

∅

3,000 Hours: 6.3 ~ 8

∅

2,500 Hours: 5

∅

1,000 Hours: 4

∅

Shelf Life Test

105°C 1,000 Hours

No Load

Max. Impedance at 100Khz & -20°C

Applicable Standards

PART NUMBER SYSTEM

NRSX 101 M 25V 6.3X11 TR F

6.3 ~ 50 VDC

1.0 ~ 15,000

µF

-55 ~ +105°C

20% (M)

0.03CV or 4

A, whichever if greater

0.01CV or 3

A, whichever if greater

W.V. (Vdc)

6.3

S.V. (Vdc)

C < 1,200

µF

0.22

0.19

0.16

0.14

C = 1,500

µF

0.23

0.20

0.17

0.15

C = 1,800

µF

0.23

0.20

0.17

0.15

C = 2,200

µF

0.24

0.21

0.18

0.16

C = 2,700

µF

0.25

0.22

0.19

0.17

C = 3,300

µF

0.26

0.23

0.20

0.18

C = 3,900

µF

0.27

0.24

0.21

0.19

C = 4,700

µF

0.28

0.25

0.22

0.20

C = 5,600

µF

0.30

0.27

0.24

C = 6,800

µF

0.32

0.29

0.26

C = 8,200

µF

0.35

0.32

0.29

C = 10,000

µF

0.38

0.35

C = 12,000

µF

0.42

C = 15,000

µF

0.48

Z-25°C/Z+20°C

Z-40°C/Z+20°C

Capacitance Change

Tan

Leakage Current

0.12

0.13

0.14

0.15

0.16

0.10

0.11

0.12

Within +

20% of initial measured value

Less than 200% of specified maximum value

Less than specified maximum value

Capacitance Change

Within +

20% of initial measured value

Tan

Less than 200% of specified maximum value

Leakage Current

Less than specified maximum value

Less than 2 times the impedance at 100Khz & +20°C

JIS C5141, C5102 and IEC 384-4

RIPPLE CURRENT CORRECTION FACTOR

Cap. (

1.0 ~ 330

390 ~ 1000

1200 ~ 2200

2700 ~ 15000

Frequency (Hz)

120

0.40

0.50

0.70

0.90

0.68

0.76

0.85

0.95

10K

0.78

0.87

0.90

1.00

100K

1.00

RoHS Compliant

= Tape &

Box

(optional)

Case Size (mm)

Working Voltage

Tolerance Code M=20%, K=10%

Capacitance Code in

µF

Series

NIC COMPONENTS

www.niccomp.com

www.lowESR.com

www.RFpassives.com
