QorIQ LS1046A and LS1026A
Processors
Quad 64-bit core processor with integrated packet processing acceleration and
high speed peripherals including 10 Gb Ethernet, PCIe
®
Gen3, SATA 3.0 and USB
3.0 for a wide range of networking, storage, security and industrial applications.
TARGET APPLICATIONS
The LS1046A and LS1026A processors are perfectly suited
for a range of embedded applications that require high CPU,
packet processing performance, and high-speed interfaces
such as 10 Gb Ethernet, PCI Express, SATA and USB.
}
Enterprise routers and switches
}
Linecard controllers
}
Network attached storage
}
Security appliances
}
Virtual customer premise equipment (vCPE)
}
Service providers gateways
}
Single board computers
OVERVIEW
The QorIQ LS1046A processor integrates four 64-bit ARM
®
Cortex-A72 cores with packet processing acceleration and
high-speed peripherals. The impressive performance of more
than 32,000 CoreMarks
®
, paired with 10 Gb Ethernet, PCIe
Gen. 3, SATA 3.0, USB 3.0 and QSPI interfaces provides a
perfect combination for a range of enterprise and service
provider networking, storage, security and industrial
applications. The LS1046A and LS1026A are available
in a 23 x 23 mm package and they are pin-compatible
with the LS1023A, LS1043A and LS1088A SoCs providing
unprecedented performance scaling for 64-bit ARM processors,
ranging from dual-A53 through octal-A53 to quad-A72
core processors, while maintaining hardware and software
compatibility. This flexible scaling enables customers to
leverage their existing software and reuse hardware design
for faster time-to-market.
QorlQ LS1046A PROCESSOR BLOCK DIAGRAM
A72
A72
A72
A72
2MB L2 cache
Secure Boot
Trust Zone
Flash Controller, QuadSPI
Power Management
SD/SDIO/eMMC
4 x UART
4 x I
2
C
SPI, GPIO, JTAG
3 x USB3.0 w/ PHY
8-Lane 10 GHz SERDES
SEC
Buffer
Mgr.
10G 10G 2.5G 1G
1G
1G
1G
Queue
Mgr.
Coherent Interconnect (CCI-400)
IO MMU
IO MMU
32 / 64-bit
DDR4
Memory Controller
IO MMU
Parse, Classify,
Distribute
SATA 3.0
PCIe 3.0
PCIe 3.0
PCIe 3.0
Core Complex
Basic Peripherals and Interconnect
Accelerators and Memory Control
Networking Elements
QorIQ LS1046A FEATURES
Features
Four ARM
®
Cortex
®
-A72 cores
2 MB L2 cache
Benefits
• Best-in-class performance, in excess of 32,000 CoreMarks
®
• Total power under 10 W at 1.2 GHz for convection cooled designs
• Efficient packet classification and distribution; hardware work
scheduling, shaping, and buffer management, offloading the general
purpose processors to concentrate their processing cycles on value
added operations.
• High-speed security protocol processing, including IPsec, SSL,
DTLS, and IKE
• SEC also supports high speed XORing for RAID 5 acceleration
ARM TrustZone
®
and NXP QorIQ
trust architecture
Rich connectivity
• Two 10 Gigabit Ethernet controllers
• One 2.5 Gigabit Ethernet controller
• Four 1 Gigabit Ethernet controllers
• Three PCIe
®
3.0 Controllers, x 4,
x 2, x 1
• Three USB 3.0 with integrated PHY
• SATA 3.0 controller
• Quad SPI
Support for hardware-based
virtualization
• Enables partitioning of physical and virtual resources on LS1046A
multicore devices for increased system flexibility
• High versatility that enables support for 802.11ac modules and
high bandwidth connectivity for ASICs, 4G/LTE, SATA and low-cost
NAND/NOR Flash
• Multiple USB 3.0 for redundant WAN fail over, storage and
configuration
• Advanced XFI, Quad SGMII for maximum Ethernet flexibility
• Secure boot, secure debug, tamper detection, secure key storage
Packet processing acceleration
Integrated security engine
www.nxp.com/QorIQ
© 2016 NXP B.V.
NXP, the NXP logo, Layerscape and QorIQ are trademarks of NXP B.V. All other product or service names are the property of
their respective owners. ARM, Cortex and TrustZone are registered trademarks of ARM Limited (or its subsidiaries) in the EU
and/or elsewhere. CoreLink is a trademark of ARM Limited (or its subsidiaries) in the EU and/or elsewhere. All rights reserved.
Document Number:
QORIQLS1046AFS REV 0
