LS1043ASE7QQB: DescriptionRISC Microprocessor; CategoryThe embedded processor and controller Microcontrollers and processors; File Size3MB，2 Pages; ManufacturerNXP; Websitehttps://www.nxp.com; Environmental Compliance

Download Datasheet Parametric Compare View All

LS1043ASE7QQB Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	LS1043ASE7QQB	-	-	View	Buy Now

LS1043ASE7QQB Overview

RISC Microprocessor

LS1043ASE7QQB Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	NXP
package instruction	FBGA,
Reach Compliance Code	compliant
Other features	ALSO OPERATES AT 1V NOMINAL SUPPLY
Address bus width	16
bit size	64
boundary scan	YES
External data bus width	32
Format	FIXED POINT
Integrated cache	YES
JESD-30 code	S-PBGA-B621
length	21 mm
low power mode	YES
Humidity sensitivity level	3
Number of terminals	621
Maximum operating temperature	105 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	FBGA
Package shape	SQUARE
Package form	GRID ARRAY, FINE PITCH
Peak Reflow Temperature (Celsius)	250
Maximum seat height	2.07 mm
speed	1600 MHz
Maximum supply voltage	0.93 V
Minimum supply voltage	0.87 V
Nominal supply voltage	0.9 V
surface mount	YES
technology	CMOS
Temperature level	OTHER
Terminal form	BALL
Terminal pitch	0.8 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	30
width	21 mm
uPs/uCs/peripheral integrated circuit type	MICROPROCESSOR, RISC

Preview

Download Datasheet

View All

Quad-core, 64-bit

ARM-based processors

designed for enterprise

edge industrial and

networking applications

QorIQ LS1043A and LS1023A

Communication Processors

The QorIQ LS1043A communications processor is our first quad-core, 64-bit

ARM

-based processor for embedded networking and industrial infrastructure.

TARGET APPLICATIONS

}

Integrated services

}

Branch office routers

}

vCPE and other edge equipment

}

Multi-protocol IoT gateways

}

Industrial PLC and control

}

Security appliances

The LS1023A (two core version) and the LS1043A (four core

version) deliver greater than 10 Gb/s of performance in a

flexible I/O package supporting fanless designs. This SoC is

a purpose-built solution for small-form-factor networking and

industrial applications with BOM optimizations for economic low

layer PCB, lower cost power supply and single clock design.

The QorIQ LS1043A delivers a next-generation performance

boost over dual-core ARM 32-bit products such as the QorIQ

LS1020A and the LS1024A processors. The LS1043A takes

ARM processing performance to the next level with up to 4x

1.6 GHz 64-bit processors and a large 1 MB L2-cache for the

best CPU performance per watt in the value-tier line of QorIQ

communications processors. This powerful CPU complex is

coupled with the proven offload engines of the QorIQ Data

Path Acceleration Architecture (DPAA) to deliver up to 10

Gb/s performance with minimal CPU overhead.

Additionally, the QorIQ LS1043A processor continues

the QorIQ legacy of I/O flexibility with up to 6x Gigabit

interfaces, 3 x PCIe

interfaces, 3 x USB 3.0 interfaces and

integrated QUICC Engine technology for legacy glue-less

HDLC, TDM or PROFIBUS support.

GENERAL PURPOSE PROCESSORS

The QorIQ LS1043A processor leverages the 64-bit ARM

Cortex-A53 core to deliver leading edge performance with

high energy efficiency. This new quad- or dual-core complex

provides a generous 1MB L2-cache and a highly efficient

eight-stage pipeline for maximum performance per watt.

The QorIQ LS1043A processor uses the high performance

CoreLink CCI 400

™

coherent interconnect with the SMMU

(ARM’s I/O MMU) to provide hardware enforced memory

access controls for accelerators and peripherals operating

on behalf of virtual machines running on the general

purpose processors.

LS1043ASE7QQB Related Products

	LS1043ASE7QQB	LS1043AXE7QQB	LS1043ASE7PQB
Description	RISC Microprocessor	RISC Microprocessor	RISC Microprocessor
Is it Rohs certified?	conform to	conform to	conform to
Maker	NXP	NXP	NXP
package instruction	FBGA,	FBGA,	FBGA,
Reach Compliance Code	compliant	compliant	compliant
Other features	ALSO OPERATES AT 1V NOMINAL SUPPLY	ALSO OPERATES AT 1V NOMINAL SUPPLY	ALSO OPERATES AT 1V NOMINAL SUPPLY
Address bus width	16	16	16
bit size	64	64	64
boundary scan	YES	YES	YES
External data bus width	32	32	32
Format	FIXED POINT	FIXED POINT	FIXED POINT
Integrated cache	YES	YES	YES
JESD-30 code	S-PBGA-B621	S-PBGA-B621	S-PBGA-B621
length	21 mm	21 mm	21 mm
low power mode	YES	YES	YES
Humidity sensitivity level	3	3	3
Number of terminals	621	621	621
Maximum operating temperature	105 °C	105 °C	105 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	FBGA	FBGA	FBGA
Package shape	SQUARE	SQUARE	SQUARE
Package form	GRID ARRAY, FINE PITCH	GRID ARRAY, FINE PITCH	GRID ARRAY, FINE PITCH
Peak Reflow Temperature (Celsius)	250	250	250
Maximum seat height	2.07 mm	2.07 mm	2.07 mm
speed	1600 MHz	1600 MHz	1400 MHz
Maximum supply voltage	0.93 V	0.93 V	0.93 V
Minimum supply voltage	0.87 V	0.87 V	0.87 V
Nominal supply voltage	0.9 V	0.9 V	0.9 V
surface mount	YES	YES	YES
technology	CMOS	CMOS	CMOS
Temperature level	OTHER	INDUSTRIAL	OTHER
Terminal form	BALL	BALL	BALL
Terminal pitch	0.8 mm	0.8 mm	0.8 mm
Terminal location	BOTTOM	BOTTOM	BOTTOM
Maximum time at peak reflow temperature	30	30	30
width	21 mm	21 mm	21 mm
uPs/uCs/peripheral integrated circuit type	MICROPROCESSOR, RISC	MICROPROCESSOR, RISC	MICROPROCESSOR, RISC
