Wire Guard |
Spacing 5.08 mm
AKZ500/..DS-5.08-V-GREY
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.2 mm²
1.5 mm²
0.2 mm²
1.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
Width (mm)
10.76
15.84
20.92
26.00
31.08
36.16
41.24
46.32
51.40
56.48
61.56
Article Designation
AKZ500/2DS-5.08-V-GREY
AKZ500/3DS-5.08-V-GREY
AKZ500/4DS-5.08-V-GREY
AKZ500/5DS-5.08-V-GREY
AKZ500/6DS-5.08-V-GREY
AKZ500/7DS-5.08-V-GREY
AKZ500/8DS-5.08-V-GREY
AKZ500/9DS-5.08-V-GREY
AKZ500/10DS-5.08-V-GREY
AKZ500/11DS-5.08-V-GREY
AKZ500/12DS-5.08-V-GREY
Article Number
50500020134G
50500030134G
50500040134G
50500050134G
50500060134G
50500070134G
50500080134E
50500090134E
50500100134E
50500110134E
50500120134E
PU
250
250
250
250
250
250
100
100
100
100
100
Stranded with Ferrule 0.2 mm²
min
Stranded with Ferrule 1.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Clamp
Wire Guard
Screw
Brass
Stainless Steel
Steel
6.0 mm
1.3 mm
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
Article Number
50000000006
Colours
GREY
BLACK
GREEN
BLUE
RAL7016
RAL9011
RAL6018
RAL5015
RAL7016
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
RAL9011
RAL6018
RAL5015
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Bridge, 2-pole, BR/2-5.0/5.08-L7.0
50000000008
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
B
300 V
15 A
AWG 22-14
AWG 22-14
0.40 Nm
M2.6
1.6 kV
C
-
-
-
-
-
-
-
D
300 V
10 A
AWG 22-14
AWG 22-14
0.40 Nm
M2.6
1.6 kV
min
0.5 mm²
0.5 mm²
250 V
17.5 A
max
1.5 mm²
1.5 mm²
0.40 Nm
M2.6
2.0 kV
