Lift |
Spacing 3.5 mm
AK601/..-3.5-V-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.08 mm²
1.5 mm²
0.08 mm²
1.0 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 3.5 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
7.40
10.90
14.40
17.90
21.40
24.90
28.40
31.90
35.40
38.90
42.40
45.90
49.40
52.90
56.40
59.90
63.40
66.90
70.40
73.90
77.40
80.90
84.40
Article Designation
AK601/2-3.5-V-GREEN
AK601/3-3.5-V-GREEN
AK601/4-3.5-V-GREEN
AK601/5-3.5-V-GREEN
AK601/6-3.5-V-GREEN
AK601/7-3.5-V-GREEN
AK601/8-3.5-V-GREEN
AK601/9-3.5-V-GREEN
AK601/10-3.5-V-GREEN
AK601/11-3.5-V-GREEN
AK601/12-3.5-V-GREEN
AK601/13-3.5-V-GREEN
AK601/14-3.5-V-GREEN
AK601/15-3.5-V-GREEN
AK601/16-3.5-V-GREEN
AK601/17-3.5-V-GREEN
AK601/18-3.5-V-GREEN
AK601/19-3.5-V-GREEN
AK601/20-3.5-V-GREEN
AK601/21-3.5-V-GREEN
AK601/22-3.5-V-GREEN
AK601/23-3.5-V-GREEN
AK601/24-3.5-V-GREEN
Article Number
50601020001F
50601030001F
50601040001F
50601050001F
50601060001E
50601070001E
50601080001E
50601090001E
50601100001D
50601110001D
50601120001D
50601130001D
50601140001D
50601150001D
50601160001D
50601170001D
50601180001D
50601190001D
50601200001D
50601210001D
50601220001D
50601230001D
50601240001D
PU
200
200
200
200
100
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 0.34 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Clamp
Screw
Solder Tag
Brass
Steel
Brass
6.0 mm
1.2 mm
Colours
RAL6018
similar RAL 6018
21
GREEN, RAL6018
LIGHT GREEN, similar RAL 6018
22
23
24
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-7.0/7.62-
L7.5-LIGHT GREY
Article Number
50000000018
Bridge, 2-pole, BR/2-5.0/5.08-L7.5
50000000015
Bridge, 3-pole, BR/3-3.5/3.81-L7.5
50000000016
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
B
150 V
10 A
AWG 28-16
AWG 28-16
0.20 Nm
M2
1.3 kV
C
-
-
-
-
-
-
-
D
-
-
-
-
-
-
-
min
0.2 mm²
0.2 mm²
130 V
10 A
max
1.0 mm²
1.0 mm²
0.20 Nm
M2
2.5 kV
www.ptr.eu
