Tension spring |
Spacing 10.0 mm
AK3001/..KD-10.0-PEBBLE GREY
1- to n-poles
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.08 mm²
2.5 mm²
0.14 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 10.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
17.90
27.90
37.90
47.90
57.90
67.90
77.90
87.90
97.90
107.90
117.90
127.90
137.90
147.90
157.90
167.90
177.90
187.90
197.90
207.90
217.90
227.90
237.90
Article Designation
AK3001/2KD-10.0-PEBBLE GREY
AK3001/3KD-10.0-PEBBLE GREY
AK3001/4KD-10.0-PEBBLE GREY
AK3001/5KD-10.0-PEBBLE GREY
AK3001/6KD-10.0-PEBBLE GREY
AK3001/7KD-10.0-PEBBLE GREY
AK3001/8KD-10.0-PEBBLE GREY
AK3001/9KD-10.0-PEBBLE GREY
AK3001/10KD-10.0-PEBBLE GREY
AK3001/11KD-10.0-PEBBLE GREY
AK3001/12KD-10.0-PEBBLE GREY
AK3001/13KD-10.0-PEBBLE GREY
AK3001/14KD-10.0-PEBBLE GREY
AK3001/15KD-10.0-PEBBLE GREY
AK3001/16KD-10.0-PEBBLE GREY
AK3001/17KD-10.0-PEBBLE GREY
AK3001/18KD-10.0-PEBBLE GREY
AK3001/19KD-10.0-PEBBLE GREY
AK3001/20KD-10.0-PEBBLE GREY
AK3001/21KD-10.0-PEBBLE GREY
AK3001/22KD-10.0-PEBBLE GREY
AK3001/23KD-10.0-PEBBLE GREY
AK3001/24KD-10.0-PEBBLE GREY
Article Number
53001020041E
53001030041E
53001040041E
53001050041E
53001060041D
53001070041D
53001080041D
53001090041D
53001100041D
53001110041D
53001120041D
53001130041D
53001140041D
53001150041D
53001160041D
53001170041D
53001180041D
53001190041D
53001200041D
53001210041D
53001220041D
53001230041D
53001240041D
PU
100
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 1.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Solder Tag
Tension Spring
Copper Alloy
Stainless Steel
6.0 mm
1.0 mm
Colours
PEBBLE GREY
GREEN
ORANGE
BLUE
LIGHT GREEN
21
RAL7032
RAL6018
RAL2011
RAL5015
similar RAL 6018
RAL7032
22
23
24
RAL6018
RAL2011
RAL5015
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Test Voltage
B
300 V
15 A
AWG 28-14
AWG 28-14
1.6 kV
C
300 V
15 A
AWG 28-14
AWG 28-14
1.6 kV
D
-
-
-
-
-
min
0.5 mm²
0.5 mm²
1000 V
24 A
max
2.5 mm²
2.5 mm²
3.5 kV
